| Dual WAN |
Dual WAN |
| Standards |
802.3, 802.3u
IPv4 (RFC 791)
Routing Information Protocol (RIP) v1 (RFC 1058) and v2 (RFC 1723) |
| Network protocols |
Dynamic Host Configuration Protocol (DHCP) server, DHCP client, DHCP relay agent
Static IP
Point-to-Point Protocol over Ethernet (PPPoE)
Point-to-Point Tunneling Protocol (PPTP)
Transparent bridge
DNS relay, Dynamic DNS (DynDNS, 3322) |
| Routing protocols |
Static
RIP v1 and v2 |
| Network Address Translation |
Port Address Translation (PAT)
Network Address Port Translation (NAPT), NAT traversal, one-to-one NAT |
| Protocol binding |
Protocols can be bound to a specific WAN port for load balancing |
| Network edge (DMZ) |
DMZ port, DMZ host |
| Firewall |
SPI, denial of service (DoS), ping of death, SYN flood, land attack, IP spoofing, email alert for hacker attack |
| Access rules |
Up to 50 entries |
| Port forwarding |
Up to 30 entries |
| Port triggering |
Up to 30 entries |
| Blocking |
Java, cookies, ActiveX, HTTP proxy |
| Content filtering |
Static URL blocking or keyword blocking |
| Web filtering |
Cisco ProtectLink Web cloud-based security service |
| Secure management |
HTTPS, username/password, password complexity |
| IPsec |
100 IPsec site-to-site tunnels for branch office connectivity |
| QuickVPN |
50 QuickVPN tunnels for remote client access |
| PPTP |
5 PPTP tunnels for remote access |
| Encryption |
Data Encryption Standard (DES), Triple Data Encryption Standard (3DES), and Advanced Encryption Standard (AES) encryption; AES-128, AES-192, AES-256 |
| Authentication |
MD5/SHA1 authentication |
| IPsec NAT traversal |
Supported for gateway-to-gateway and client-to-gateway tunnels |
| VPN pass-through |
PPTP, L2TP, IPsec |
| Advanced VPN |
Dead peer detection (DPD), IKE, split DNS, VPN backup |
| Prioritization types |
Application-based priority on WAN port |
| Service-based QoS |
Supports rate control or priority |
| Rate control |
Upstream/downstream bandwidth can be configured per service |
| Priority |
Each service can be mapped to one of 3 priority levels |
| NAT throughput |
200 Mbps |
| IPsec VPN throughput |
97 Mbps |
| Web user interface |
Simple browser-based device manager (HTTP/HTTPS) |
| Management protocols |
Web browser, Simple Network Management Protocol (SNMP) v1 and v2c, Bonjour |
| Event logging |
Syslog, email alerts, VPN tunnel status monitor |
| Upgradability |
Firmware upgradable through web browser, imported/exported configuration file |
| Ports |
8 10/100 RJ-45 ports, 1 10/100 RJ-45 Internet port, 1 10/100 RJ-45 DMZ/Internet port |
| Power |
AC 100 - 240V, 50 - 60Hz |
| Certification |
FCC class B, CE Class A, cUL, Anatel, MEPS, CCC, PSB, CB, C-tick, KCC |
| Operating temperature |
0 Deg. to 40 Deg.C (32 Deg. to 104 Deg.F) |
| Storage temperature |
0 Deg. to 70 Deg.C (32 Deg. to 158 Deg.F) |
| Operating humidity |
10% to 85% noncondensing |
| Storage humidity |
5% to 90% noncondensing |
| Dimensions (W x H x D) |
11.00 in. x 1.75 in. x 9.50 in. / 279.4 mm x 44.45 mm x 241.3 mm |
