| Image Device |
1/4" CMOS |
| Pixels |
310,000 |
| Control |
White Balance: Auto Exposure mode: Auto Gain: Auto |
| Lens |
Viewing angle: Horizontal: 60°, Vertical: 45° Focal length: f=3.6mm Aperture: F2.0mm |
| Min. Illumination |
1.0 Lux |
| Network |
Image compression: MPEG-4, MJPEG Image resolution: 640×480(VGA), 320×240(QVGA), 160×120(QQVGA) Max. frame rate: 30fps @640×480 Audio compression: G.726 (40/32/24/16Kbps) Built-in microphone: Electret Condenser Microphone |
| Network Function |
Simultaneous viewers: 16 Authentication: ID/Password, Administrator/General User (Up to 64) Network protocols TCP, UDP, IP, ARP ,ICMP, DHCP, DNS, HTTP, FTP, SMTP, NTP, PPPoE, DDNS, UPnP Automatic discovery and configuration Stream Type: RTSP/RTP/RTCP, 3GPP, ASF Network connection: Ethernet (10BASE-T/100BASE-TX) |
| Wireless LAN |
Wireless technology: IEEE802.11b/g Frequency: 2.412-2.462GHz Transmission speed: 54Mbps / 22Mbps / 11Mbps/ 5.5Mbps / 2Mbps / 1Mbps (Auto Switch) Security: WEP (64/128 bit),WPA, WPA2 |
| PC System Minimum Requirements |
Operating system: Windows 2000/XP/Vista/Windows 7/Windows 7 Processor: Intel Pentium III, 800MHz or Higher Memory: 128MB RAM Minimum Web browser: Most browsers supported. Internet Explorer 5.5 or higher, Mozilla Firefox, Safari, Chrome. |
| Mac System Minimum Requirements |
Operating system: Mac OSX 10.4 Tiger Processor: 800MHz PowerPC G4 or Intel Memory: 128MB RAM (256Mb or higher recommended) Web browser: Safari, Mozilla Firefox, Chrome. Most browsers supported |
| General |
Power requirements: DC 5V Power consumption: 3.25W Operating temperature: -5 to +45 °C (+22 to +113 °F) Storage temperature: -20 to +60 °C (-4 to +140 °F) Operating humidity: 20-80%RH (Non-condensing) Storage humidity: 20-95%RH (Non-condensing) Dimensions (WxDxH): 3.3 x 3.3 x 1.2" / 85 x 85 x 30mm Weight: 5.3 oz / 150g (Main Body) |
