Sony FWD-S42E1TOUCH 42inch Interactive LCD Touch Screen
Sony FWD-S42E1TOUCH 42" Interactive LCD Touch Screen FWDS42E1TOUCH
SKU: SOFWDS42E1T MFR: FWDS42E1TOUCH
What's Included
What's Included With This Item:
- Sony FWD-S42E1TOUCH 42inch Interactive LCD Touchscreen Monitor
- AC Power Cord and Plug Holder
- Remote Control
- 2 x AA Batteries
- Operating Instructions
- Sony Warranty
Why Adorama?
Need help? Call 800-223-2500 / 212-741-0052
The Sony FWD-S42E1TOUCH 42" Interactive LCD Touchscreen Monitor integrates full touch screen functionality directly into the FWD-S42E1's factory enclosure, adding significant value to this slim, environmentally friendly public display monitor. Combining high image quality with a small footprint, the FWD-S42E1TOUCH's full 1920 x 1080 HD display can be shown in either landscape or portrait mode, taking advantage of its fast response time and a stellar contrast ratio to make your images shine. Meanwhile, behind the scenes, an innovative backlight design ensures that the monitor uses less than 100W of power.
A host of other features complement this stylish, high-performance unit, including 4 picture modes, 3 screen saver functions, 3 gamma settings, DVI and RGB inputs and RS-232 control. The FWD-S42E1TOUCH's sturdy build and power efficiency provide it with the durability and cost savings necessary for 24/7 operation in high-traffic environments, making it a go-to monitor for such applications as digital signage, video security and corporate presentation--not to mention the kind of interactive installations found in museums, learning centers, hospitals and stadiums.
- Sony FWD-S42E1TOUCH 42inch Interactive LCD Touchscreen Monitor
- AC Power Cord and Plug Holder
- Remote Control
- 2 x AA Batteries
- Operating Instructions
- Sony Warranty
- Touch Screen Integration: Using 3M's optically clear Dispersive Touch Technology (DST) within Sony's factory LCD housing, the touchscreen is designed for high-traffic, high-use environments, serving as an extra layer of protection for the LCD panel itself
- The Benefits of DST: Dispersive Touch Technology combines chemically strengthened glass with an anti-glare surface and extremely fast and accurate response times. It supports gesture functions and offers users a standard USB 2.0 touch interface
- Eco Power Consumption: By reworking the design of the earlier S42H1, Sony can now offer a lower power consumption of less than 100W--more environmentally friendly
- Video Walls and Multiple Messaging: Full HD, sleek thin bezel design, slim profile and overscan on/off mode enable the S42E1 to create the most visibly stunning video walls and the sharpest messaging systems
- Device On/Off Control via HDMI CEC: By combining the S42E1 with the HDMI board (BKM-FW15) you can now optimize the use of the display by synchronizing the standby mode of the display with the HDMI source you are using
- Broadcast Compatible: With the full range of HD inputs DVI as standard and optional HDMI and HDSDI--the S42E1 can bring full HD high-contrast viewing to broadcast applications, ensuring production staff, clients and other interested parties enjoy a true full HD representation of content
- Digital Signage Compatible: The full HD, wide angle viewing enables pin sharp messaging from a distance and close-up, day or night. Compatibility with Sony BKM-FW50/55 digital signage system makes these public displays ideal for strong, vibrant messaging throughout offices, airports, train stations
- Suitable for Video Security Environments: The clarity of full HD combined with the low power consumption creates a more productive environment for security professionals viewing multiple screens
- Landscape/Portrait: Unique Sony LCD technology has overcome the "gravity gap" issues sometimes seen with plasma and other manufacturers' LCD units, ensuring operation in landscape or portrait mode without compromising performance
- Robust and Slim: The 19mm bezel has been designed to offer maximum visibility, while providing the sturdy protection and robustness you need for reliable operation in retail leisure and corporate applications
- Wider Choice of Network Options: Equipped with an RS232 input, a complete range of HD inputs compatible with Sony BKM-FW50/55 SD digital signage system and next-generation boards, displays will work in virtually any application from professional broadcast/retail, to corporate and security markets
- Four Picture Modes: Includes vivid display with brightness boost, standard, fixed custom settings, conference mode for optimum pictures with fluorescent lights
- Three Screen Saver Functions: Choose from revert to standby, all white, or a scrolling sweep, based on inactivity time intervals from 30 minutes to 23 hours
- Three Gamma Settings: Choose from high, mid and low
| Signal System |
PAL, NTSC, PAL-M, PAL-N, PAL60, NTSC4.43 |
| Monitor Type |
a-Si TFT Active Matrix LCD |
| Screen Size |
42"/106.68 cm |
| Resolution |
1920 x 1080 |
| Pixel Pitch |
0.48mm |
| Colors |
1.06 Billion |
| Viewing Angle |
178deg. |
| Brightness |
500cd/m2 (max, before touch screen) |
| Contrast Ratio |
1000:1 |
| Response Time |
8ms |
| Connections |
RGB/Component: 15-pin D-Sub (x1 Input)
DVI: DVI (x1 Input)
Audio: 3.5mm Mini (x2 Input)
RS-232C: 9-pin D-Sub (x1 Input)
Control S: 3.5mm Mini (x1 Output) |
| Remote Control |
Yes |
| Touch Screen |
Construction: Glass, chemically-strengthened anti-glare substrate
Input Method: Finger and stylus input
Positional Accuracy: Reported coordinates are within 1.0% of true position
Light Transmission: Up to 92%
Operating Temperature: -15deg.C to 90deg.C
Minimum Touch Impact: 50 mN.s, the equivalent of a very light touch
Response Time: 20 ms for tap input
Expected Life Performance: No known wear-out mechanism, as there are no layers, coating, or moving parts |
| Power Requirements |
100-240VAC, 50/60Hz, 1.6A |
| Power Consumption |
98W (typical)
160W (max) |
| Dimensions (W x H x D) |
38.3 x 22.2 x 5.2" (97.2 x 56.5 x 13.1 cm) |
| Weight |
56 lbs (25.4kg) |
