| SDI Video Input |
Switchable between SD, HD and 3 Gb/s SDI |
| SDI Video Outputs |
Switchable between SD, HD and 3 Gb/s SDI |
| Dual Rate Support |
Auto detection of HD or standard definition SDI inputs |
| Updates and Configuration |
Via USB 2.0 high speed. (480 Mb/s) |
| Re-clocking |
Yes |
| Analog Audio |
2 channels of professional balanced analog audio with XLR connections |
| HDMI |
HDMI in and out |
| Analog Video |
Component, NTSC, PAL and S-Video |
| SDI Format Support |
625/25 PAL, 525/29.97 NTSC, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080i50, 1080i59.94, 1080i60, 720p50, 720p59.94 and 720p60 |
| SDI Compliance |
SMPTE 292M, SMPTE 259M, SMPTE 296M, ITU-R BT.656 and ITU-R BT.601 |
| SDI Video Sampling |
4:2:2 |
| SDI Video Rates |
SDI video connections are switchable between standard definition and high definition |
| SDI Color Precision |
4:2:2 |
| SDI Color Space |
YUV |
| SDI Audio Sampling |
Television standard sample rate of 48 kHz and 24 bit |
| SDI Auto Switching |
Automatically selects between SD SDI, HD-SDI and 3 Gb/s SDI |
| Analog Format Support |
625/25 PAL, 525/29.97 NTSC, 1080PsF23.98, 1080PsF24, 1080i50, 1080i59.94, 1080i60, 720p50, 720p59.94 and 720p60 |
| Analog Color Precision |
4:2:2 |
| Analog Color Space |
YUV |
| HDMI Format Support |
625/25 PAL, 525/29.97 NTSC, 625/50p PAL, 525/59.94p NTSC, 1080p23.98/24, 1080i50, 1080i59.94/60, 720p50 and 720p59.94/60 |
| HDMI Color Precision |
4:2:2 and 4:4:4 |
| HDMI Color Space |
YUV and RGB |
| Software Control |
Mac OS X and Windows software upgrade via USB |
| Settings Control |
Via USB software |
| Firmware Upgrade |
Via included firmware updater application |
| Power Supply |
+12V universal power supply included; Cable tie point |
| Warranty |
Blackmagic Design 3 Year Limited Warranty |
