| EXP-7500U2 Speaker: Power Output |
75W |
| EXP-7500U2 Speaker: Speakers |
6.5" Woven Fiber Woofer
Horn Tweeter |
| EXP-7500U2 Speaker: SPL |
110dB @ 1m |
| EXP-7500U2 Speaker: Battery Type |
Built-In rechargeable battery and charger |
| EXP-7500U2 Speaker: Frequency Response |
80Hz - 16kHz |
| EXP-7500U2 Speaker: Inputs |
2 x XLR Female Balanced Microphone
2 x L, R RCA Phono Unbalanced Line
1 x 1/4" TS Phone Unbalanced Line
1 x 12 VDC In |
| EXP-7500U2 Speaker: Output |
1 x 1/4" Phone Companion Speaker Out(2 Ohm)
2 x L, R RCA Phono Unbalanced Line
1 x 1/4" TRS Phone Balanced Line |
| EXP-7500U2 Speaker: AC Power |
90 - 264VAC, 50/60Hz |
| EXP-7500U2 Speaker: Wireless Receiver |
UHF x 2 |
| EXP-7500U2 Speaker: Microphone Type |
No |
| EXP-7501 Speaker: Low Frequency Driver |
6.5" woven fiber woofer |
| EXP-7501 Speaker: Mid Frequency Driver |
No |
| EXP-7501 Speaker: High Frequency Driver |
1" Horn-loaded tweeter |
| EXP-7501 Speaker: Frequency Range |
80 Hz - 16 kHz |
| EXP-7501 Speaker: Impedance |
8 Ohms |
| EXP-7501 Speaker: Maximum Power Handling |
60 Watts |
| EXP-7501 Speaker: Maximum Sound |
110dB @ 1m Pressure Level (SPL) |
| EXP-7501 Speaker: Controls & Indicators |
No |
| EXP-7501 Speaker: Connectors |
1 x Speakon |
| EXP-7501 Speaker: Shielded |
No |
| Headband Mic: Transducer |
Electret condenser |
| Headband Mic: Polar Pattern |
Uni-directional |
| Headband Mic: Frequency Response |
30Hz to 15kHz |
| Headband Mic: Dynamic Range (Typical) |
Sensitivity: -48dB @ 1kHz |
| Headband Mic: Power Requirements |
1-10 volts DC |
| Headband Mic: Output Impedance |
Lo-Z |
| Headband Mic: Output Connectors |
TA4F (mini XLR female) |
| Headband Mic: Cable |
36" / 91.44 cm |
| Dimensions (H x W x D) |
EXP-7501 Speaker: 16.5 x 10.5 x 10" (420 x 270 x 250mm)
EXP-7500U2 Speaker: 16.5 x 10.5 x 10" (420 x 270 x 250mm) |
| Weight |
EXP-7500U2 Speaker: 23 lbs (10.4kg)
Headband Mic: 0.07 oz |
