| Studio Microphone: Tube Type |
Pressure gradient condenser capsule |
| Studio Microphone: Diaphragm |
3 micron gold-sputtered |
| Studio Microphone: Frequency Response |
20Hz - 20kHz |
| Studio Microphone: Polar pattern |
Cardioid |
| Studio Microphone: Sensitivity |
15mV/Pa |
| Studio Microphone: Output Impedance |
150 ohms |
| Studio Microphone:Pre-Attenuation Switch |
0 dB, -10 dB |
| Studio Microphone: High Pass Filter |
6 dB / octave @ 150 Hz |
| Studio Microphone: Equivalent noise |
16 dB (A-weighted IEC 268-4) |
| Studio Microphone: S / N Ratio |
76 dB (Ref. 1 Pa A-weighted) |
| Studio Microphone: Max SPL for .5% THD |
130 dB/140 dB (0dB, -10 dB pad) |
| Studio Microphone: Power Requirements |
48V Phantom Power (+ / - 4V) |
| Instrument Microphone: Tube Type |
Pressure gradient condenser microphone |
| Instrument Microphone: Diaphragm |
6 micron gold-sputtered |
| Instrument Microphone: Capsule Size |
22mm/.87 in. |
| Instrument Microphone:Frequency Response |
30Hz - 20kHz |
| Instrument Microphone: Polar pattern |
Cardioid |
| Instrument Microphone: Sensitivity |
10mV/Pa |
| Instrument Microphone: Output Impedance |
200 ohms |
| Instrument Microphone: Equivalent noise |
18 dB (A weighted IEC 268-4) |
| Instrument Microphone: S / N Ratio |
76 dB (Ref. 1 Pa A-weighted) |
| Instrument Microphone: Max SPL (.5% THD) |
134 dB |
| Instrument Microphone: Power Required |
48V phantom power (+ /-4V) |
| Studio Microphone: Dimensions |
47 x 215mm/1.85 x 8.46 in |
| Instrument Microphone: Dimensions |
22mm x 133mm/5.24 in. X 0.87 in |
| Studio Microphone: Weight |
1.3 lb/0.58 kg |
| Instrument Microphone: Weight |
0.3 lbs/136.08g |
