| Enclosure Type |
Desktop |
| Connectivity Technology |
Wireless, wired |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Capacity |
Virtual interfaces (VLANs): 10, IPSec VPN tunnels: 5 |
| Network / Transport Protocol |
TCP/IP, PPTP, UDP/IP, L2TP, ICMP/IP, PPPoE, PPPoA, IPoA |
| Routing Protocol |
RIP-1, RIP-2, IGMPv2, IGMP, static IP routing, GRE, policy-based routing (PBR) |
| Remote Management Protocol |
SNMP 1, SNMP 2, SNMP 3, HTTP, HTTPS |
| Encryption Algorithm |
DES, Triple DES, 128-bit WEP, 64-bit WEP, TKIP, WPA, WPA2 |
| Authentication Method |
RADIUS, Radio Service Set ID (SSID) |
| Compliant Standards |
IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.11b, IEEE 802.3ad (LACP), IEEE 802.11g, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11n, UPnP |
| RAM |
64 MB |
| Flash Memory |
32 MB |
| Status Indicators |
Power, phone, WLAN, WAN, LAN |
| VoIP Functionality |
VoIP phone adapter |
| VoIP Protocols |
SIP v2 |
| Voice Codecs |
G.711, G.723.1, G.729ab, G.726, T.38 |
| Telephony Interfaces |
1 line (FXO), 4 phone (FXS) |
| Interfaces |
LAN: 4 x 10Base-T/100Base-TX/1000Base-T, RJ-45, Phone line: 1 x FXO, RJ-11, Phone line: 4 x FXS, RJ-11, Hi-Speed USB: 2 x 4 pin USB Type A, WAN: 2 x 10Base-T/100Base-TX/1000Base-T, RJ-45 |
| Antenna |
External detachable |
| Antenna Qty |
2 |
| Gain Level |
2.2 dBi |
| Power Device |
Power adapter, external |
| Voltage Required |
AC 120/230 V |
| Compliant Standards |
CISPR 24, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, CISPR 22, EN50082-1, AS/NZS 60950-1, RSS-210, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, FCC Part 15, CS-03, EN 61000-4-5, EN 6100 |
| Min Operating Temperature |
32Deg.F |
| Max Operating Temperature |
104Deg.F |
| Humidity Range Operating |
5, 95% (non-condensing) |
