| UHF Receiver - Receiving System |
PLL Synthesized, 64 CH |
| UHF Receiver - Frequency Stability |
± 0.005% |
| UHF Receiver - S/N Ratio |
> 94 dB, 48KHz deviation & 60 dBµV antenna input |
| UHF Receiver - Rejection |
80 dB minimum |
| UHF Receiver - Sensitivity |
6 dBµV |
| UHF Receiver - Selectivity |
> 50 dB |
| UHF Receiver - AF Response |
50 Hz - 15 KHz (± 3 dB) |
| UHF Receiver - T.H.D. |
< 1% (@ 1 KHz) |
| UHF Receiver - Modulation Mode |
FM |
| UHF Receiver - IF Frequency |
1st 56 MHz / 2nd 10.7 MHz |
| UHF Receiver - Dynamic Range |
> 96 dB |
| UHF Receiver - Tone Signal |
32.768 KHz |
| UHF Receiver - Audio Output |
Balanced & unbalanced |
| UHF Receiver - Power Supply |
12V DC |
| UHF Receiver - Frequency Stability |
± 0.005% |
| UHF Receiver - Dimensions (HxWxD) |
1.77 x 16.54 x 7.1" (45 x 420 x 180 mm) |
| Transmitter - RF Power Output |
10mW |
| Transmitter - Oscillation Mode |
PLL synthesized |
| Transmitter - Frequency Stability |
± 0.005% |
| Transmitter - Max. Deviation |
± 48 KHz |
| Transmitter - Spurious Emission |
> 60 dB below carrier freq. |
| Transmitter - Sensitivity |
6 dBµV |
| Transmitter - T.H.D. |
< 1% (@ 1 KHz) |
| Transmitter - Tone Key |
32.768 KHz |
| Transmitter - Operating Voltage |
2 x DC 1.5V "AA" batteries |
| Transmitter - Consumption |
65 mA ± 10 mA |
| Transmitter - Operating Time |
20 hours |
| Body Pack Dimensions |
3.86 x 2.60 x 1.02" (98 x 66 x 26 mm) |
| Headband Mic - Transducer |
Electret condenser |
| Headband Mic - Polar Pattern |
Uni-directional |
| Headband Mic - Frequency Response |
30Hz to 15kHz |
| Headband Mic - Dynamic Range (Typical) |
Sensitivity: -48dB @ 1kHz |
| Headband Mic - Power Requirements |
1-10 volts DC |
| Headband Mic - Output Impedance |
Lo-Z |
| Headband Mic - Output Connectors |
TA4F (mini XLR female) |
| Headband Mic - Dimensions |
Cable: 36" |
| Headband Mic - Weight |
0.07 oz |
