| Transmitter System Range |
Up to 200' line of sight |
| Transmitter Frequency Range |
UHF 682- 698MHz or 863 - 865MHz |
| Transmitter RF Power Output |
682 - 998MHz @ 100 mW
863 - 865MHz @ 10 mW |
| Transmitter Frequency Stability |
± 0.005% |
| Transmitter Maximum Deviation |
± 48 KHz w/ limiting compressor |
| Transmitter Spurious Emission |
> 60 dB below carrier frequency |
| Transmitter T.H.D |
< 1% @ 1KHz |
| Transmitter Power Supply |
DC 12 ~ 18 V |
| Transmitter Tone Key |
32.768 KHz |
| Transmitter Current Consumption |
85 mA ± 10 mA (10 mW) |
| Receiver System Range |
Up To 200' line of sight |
| Receiver Frequency Range |
UHF 682 - 698MHz or 863 - 855MHz |
| Receiver Oscillator |
PLL synthesized |
| Receiver Receiving Mode |
Single channel diversity |
| Receiver Frequency Stability |
± 0.005% |
| Receiver Receiving Sensitivity |
@ 5dBuV over 80 dB S/N ratio |
| Receiver Image & Spurious |
80 dB min |
| Receiver Selectivity |
> 50 dB |
| Receiver Modulation Mode |
FM |
| Receiver IF Frequency |
1st 56 MHz / 2nd 10.7 MHz |
| Receiver Dynamic Range |
> 96 dB |
| Receiver S/N Ratio |
> 94 dB @ 15KHz deviation & 60 dBuV antenna input |
| Receiver AF Headphone |
100 Hz - 10 KHz (± 3 dB) |
| Receiver AF Response Line |
40 Hz - 15 KHz (± 3 dB) |
| Receiver T.H.D |
< 1% @ 1KHz |
| Receiver Power Supply |
DC 3V (2 x 1.5 V AA batteries) |
| Receiver Headphone Stereo |
20 mW |
| Receiver Line Stereo Level |
-10 dB |
| Receiver Current Consumption |
130 mA ± 10 mA |
| Receiver Dimensions (WxHxD) |
3 x 4.2 x 1.1" / 76 x 106 x 29 mm |
| Transmitter Dimensions (WxHxD) |
8.3 x 1.7 x 7.1" / 211 x 44 x 180 mm |
| Warranty |
Anchor Audio 2 years warranty |
