| Processor |
2x 2.4GHz Quad Intel Xeon E5620 "Westmere" |
| Cache |
L3: 12MB |
| Memory |
Slots: 8x DIMM Slots Type: 1066MHz PC3-8500 DDR3 ECC DIMM Installed: 6GB (6x1GB) RAM Capacity: 32GB Configuration: 1GB, 2GB, or 4GB DIMMs |
| Graphics Display |
Interface: Double-wide 16-lane PCI Express 2.0 graphics slot Installed: ATI Radeon HD 5770 with 1GB of GDDR5 SDRAM with support for up to three displays; Up to six displays supported via installation of a second ATI Radeon HD 5770 card Supported Resolutions Digital: 2560 x 1600 Analog: 2048 x 1536 |
| Hard Drive |
Fixed Bays: 4x Independent 3Gb/s Serial ATA cable-free, direct attach hard drive bays; 4x internal hard drive carriers included Installed: 1x 1TB 7200rpm with 32MB Cache Supported: 4x SATA Hard Drives Type: Serial ATA, supports up to 300MB/sec data throughput per hard drive |
| Optical Drive |
18x SuperDrive with double-layer support Reads CD: 32x DVD: 18x Writes CD-R: 32x CD-RW: 32x DVD-R: 18x DVD-RW: 6x DVD-R DL: 8x DVD+R: 18x DVD+RW: 8x DVD+R DL: 8x |
| Bay Expansion |
3.5" Internal Direct Attach Hard Drive Bays Bays: 4 Occupied: 1 5.25" Optical Drive Bays: 2 Occupied: 1 |
| PCI Expansion |
3x open full-length PCI Express 2.0 expansion slots 1x PCI Express 2.0 x16 slot 2x PCI Express 2.0 x4 slots All slots provide mechanical support for 16-lane cards 300W combined max for all PCI Express slots |
| Ports |
4x FireWire-800 (2x Front, 2x Back) 5x USB 2.0 (2x Front, 3x Back) 2x USB 2.0 ports on included keyboard |
| Display |
2x Mini DisplayPort 1x Dual-Link DVI Optional video adapters are available for: Additional DVI output using Mini DisplayPort to DVI Adapter; Additional Dual-Link DVI output using Mini DisplayPort to Dual-Link DVI Adapter; VGA output using MiniDisplayPort to VGA Adapter or DVI to VGA Display Adapter |
| Storage |
No |
| Audio |
1x Built-In Speaker 1x 1/8" (3.5mm) Headphone (1x Front) 1x 1/8" (3.5mm) Line-Out (1x Back) 1x 1/8" (3.5mm) Line-In (1x Back) 1x Toslink Optical Input (1x Back) 1x Toslink Optical Output (1x Back) Multichannel audio also supported through Mini DisplayPort |
| Video |
No |
| Wired |
2x independent 10/100/1000BASE-T Ethernet (RJ-45) interfaces with support for jumbo frames |
| Wireless |
Wi-Fi: 802.11a/b/g/n Airport Extreme Bluetooth: 2.1+EDR |
| Operating System |
Mac OS X 10.6 Snow Leopard |
| Electrical Requirements |
Meets ENERGY STAR requirements AC: 100-120VAC or 200-240VAC Frequency: 50-60Hz, single phase Current: 12A (low-voltage range), 6A (high-voltage range) |
| Environmental Requirements |
Operating Temperature: 50-95deg.F (10-35deg.C) Humidity: 5-95%, non-condensing Altitude: 10,000' (3048 m) Storage Temperature: -40-116deg.F (-40-47deg.C) Humidity: 5-95%, non-condensing Altitude: 10,000' (3048 m) |
| Dimensions (W x H x D) |
8.1 x 20.1 x 18.7" (20.6 x 51.1 x 47.5cm) |
| Weight |
41.2 lb (18.7kg) |
