| Triggers |
16 Velocity and Pressure Sensitive Pads |
| Polyphony |
32 |
| Data Format |
16-bit Linear WAV |
| Sampling Rate |
44.1kHz |
| Recording Time |
136 seconds (16MB Mono) (Can be Increased to Approximately 24.5 minutes with Optional 128MB Expansion) |
| Presets |
2 x 2-Pole Filters Per Voice
24 x Active Programs (64 Pads Per Program) |
| User Memory |
No |
| Effects |
Chorus, Flanger, 4-Band EQ, Bit-Grunger, Compressor, Phaser, Tremolo, Auto Pan, Reverb (Master Effects = 4-Band EQ and Compressor) |
| Sequencer |
99 Sequences, 64 Tracks Per Sequence, 100,000 Notes Total
32 MIDI Output Channels
20 Songs, 250 Steps Per Song in Song Mode |
| Controllers |
2 x Footswitch Jacks
2 x Q-Link Sliders |
| Connectors |
2 x MIDI In
2 x MIDI Out
1 x USB Port
1 x S/PDIF Digital Coaxial In
1 x S/PDIF Digital Coaxial Out
1 x 1/4" Stereo Input (2 Jacks)
1 x 1/4" Stereo Output (2 Jacks)
4 x 1/4" Assignable Mix Outputs
2 x Footswitch Jacks
1 x Headphone Output
1 x Power Input |
| Expansion Slots |
1 x CompactFlash Slot (Accepts Cards up to 2GB)
1 x Slot for Optional EXM128 RAM Expansion |
| Sample RAM |
16MB (Expandable to 128MB) |
| Storage |
16MB Internal Memory (Expandable to 128MB)
1 x CompactFlash Slot (Accepts Cards up to 2GB)
Data Backup to Mac or PC via USB
Optional Internal Hard Drive May Be Installed |
| Display |
240 x 64 Backlit Graphic LCD |
| Dimensions (H x W x D) |
3 x 13 x 9" (76 x 330 x 228mm) |
| Weight |
7.6 lbs (3.45kg) |
