| Triggers |
16 trigger pads |
| Polyphony |
64 |
| Data Format |
SEQ, WAV, PGM, SND, |
| Sampling Rate |
44.1kHz |
| Recording Time |
12m 48sec. (64MB, MONO), 38m24sec. (192MB, MONO) |
| Presets |
128 |
| User Memory |
64-192MB |
| Effects |
4 stereo busses with 2 stereo effects per buss and 4 band EQ/Compressor |
| Sequencer |
Maximum events: 100,000 notes
Resolution: 960 parts per 1/4-note
Sequences: 99
Tracks per sequence: 64
MIDI output channels: 64 (16 channels x 4 outputs)
Song mode: 20 songs, 250 steps per song
Drum pad: 16 (velocity and pressure sensitive)
Drum pad banks: 4
Sync mode: MIDI clock, MIDI Time Code
Transport Controls: MIDI Machine Control |
| Controllers |
16 (velocity and pressure sensitive) |
| Connectors-1 |
Record input (L and R): MIC/ 1/4-inch Combo x 2 balanced -40dBu, input impedance 11k ohms; RCA with PHONO preamp
Max. Input level: +10dBu
Digital RCA-pin x 1 S/PDIF
Stereo output: 1/4-inch phone x 2 balanced +11dBu, output impedance 1k Ohms
Max. output level: +22dBu
|
| Connectors-2 |
8 individual outputs: 1/4-inch phone x 8 balanced +11dBu, output impedance 1k Ohms
Max. output level: +22dBu
Phones output: 1/4-inch stereo phone x 1, 200mW / 100 ohms
Digital output: RCA-pin x 1 S/PDIF
ADAT Optical: x 1 (8 Channels)
MIDI inputs: 5-pin DIN x 2
MIDI outputs: 5-pin DIN x 4
USB: Slave connector x 1, USB MASS STORAGE CLASS support
Footswitches: 1/4-inch x 2 |
| Expansion Slots |
EXM-E3: 128MB expansion memory card (Upgrades unit to 192MB total)
CDM-25: CDR/DVD Drive |
| Sample RAM |
64MB |
| Storage |
Memory Card Slot: Compact Flash (The size of the compact flash card that MPC5000 can handle is from 32MB to 2GB) |
| Display |
240 x 128 dot graphic LCD w/back light |
| Dimensions |
18 x 16.1 x 3.4" (406.4 x 407.98 x 85.7mm) |
| Weight |
18.2 lbs (8.25kg) |
