ARRI T1 Location 1000W Fresnel, Pole Operated

SKU: AR551105

This item is no longer available.

Overview
Compare
Accessories
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the main use of the Arri T1 Location 1000W Fresnel?

The Arri T1 Location 1000W Fresnel is primarily used as a lighting fixture for professional film and television production. Its pole-operated design allows for easy adjustment of light's intensity and direction.

What are some of the improvements in the Arri T1 Location 1000W Fresnel?

The Arri T1 Location 1000W Fresnel features over 30 improvements, including reduced weight, compact size, and maximum light output. It also has a unique cross cooling system that reduces lamp housing and lens temperatures, enhancing the durability of the equipment.

What is the light output of the Arri T1 Location 1000W Fresnel?

When equipped with a 1000 watt bulb, the Arri T1 Location 1000W Fresnel can project a 2.8' diameter beam of 409 foot-candles from a distance of 20' at full spot. At full flood from the same distance, it can provide a 48 foot-candle, 20.4' diameter beam.

What is the True Blue Series?

The True Blue Series is a line of lighting fixtures from Arri. It incorporates global feedback and technological advancements to deliver a series of Fresnels with over 30 improvements for studio and location lighting.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

ARRI T1 Location 1000W Fresnel Specifications

General

General

Jump to...
  • Socket

    G22 Bi Pin

  • Color Temperature

    3200K

  • Lighting Type

    Fresnel

  • Fixture Type

    Fresnels

  • Number of Heads/Lights

    1

  • Rating

    120 to 240 VAC, 50 / 60 Hz

  • Maximum Watts

    1000 W

  • Power Connection Type

    AC Power Plug

  • Voltage

    120-240 VAC

Mounting

Jump to...
  • Lamp Base Type

    G22

  • Mount

    C-Clamp (via Included Yoke Mount)

Physical Details

Jump to...
  • Dimensions

    14.1 x 12.7 x 8.8" / 35.8 x 32.3 x 22.4 cm (Head Only)

  • Weight

    13 lb / 5.9 kg

Miscellaneous

Jump to...
  • Base Models/Kit Models

    Base Models

10 Accessories for ARRI T1 Location 1000W Fresnel, Pole Operated

  • All Accessories (10)
  • Filter Accessories (1)
  • Bags & Cases (2)
  • Production Accessories (1)
  • Clamps (1)
  • Fresnel Lens (1)
  • Adapters & Mounts (1)
  • Filters & Gels (1)
  • Diffuser (1)
  • Light Meters & Accessories (1)

About ARRI T1 Location 1000W Fresnel

If you're seeking a robust and versatile lighting solution for your film or television production, look no further than the Arri T1 Location 1000W Fresnel, a pole-operated lighting fixture that is part of the renowned True Blue Series. This upgraded model is a testament to Arri's commitment to innovation, incorporating over 30 enhancements based on global feedback and technological advancements.

The T1 Location 1000W Fresnel is not just a lighting fixture; it's a compact powerhouse designed for both studio and location lighting. Despite its reduced weight and compact size, it delivers maximum light output, making it an indispensable tool for professionals in the industry.

One of the standout features of this Fresnel light is Arri's unique cross cooling system. This innovative design reduces the lamp housing temperature by 25% and the lens temperature by 17%, ensuring the longevity of the equipment and the safety of the users. The system utilizes special air channels built into the aluminum extrusion, allowing a constant stream of air to circulate around the Fresnel lens and into the lamphead, regardless of the tilt angle.

When equipped with a separately available 1000 watt bulb, the T1 Location 1000W Fresnel can project a 2.8' (0.9 m) diameter beam of 409 foot-candles from a distance of 20' (6.1 m) at full spot. At full flood from the same distance, it can provide a 48 foot-candle, 20.4' (6.2 m) diameter beam. This flexibility in light intensity and direction makes it an ideal choice for a wide range of filming or photography scenarios.

In summary, the Arri T1 Location 1000W Fresnel, Pole Operated, is a durable, high-quality, and reliable lighting solution that offers professional-grade performance and versatility.

ARRI T1 Location 1000W Fresnel Features

  • Pressure die cast and extruded aluminum components
  • Many components now offer greater strength and resistance to corrosion
  • Patent-pending connector and strain relief rotate to allow quick cable adjustment for hanging or stand mounting
  • Improved (optional) barndoors are stronger and less susceptible to bending
  • New hinge design maintains constant tension and may be easily adjusted
  • Stirrup mounting slides can be adjusted to counterbalance all accessories
  • Soft contour makes the Fresnel comfortable to carry
  • The stainless steel friction disc locks securely even when large front-mounted accessories are being used
  • Routine maintenance and repair are easier with fast, simple access to all internal components
  • Cleaning is almost effortless with smooth lamp housing surfaces
  • Meets IP23 standard - suitable for indoor use or outdoor use providing a degree of protection against falling rain (up to a 60deg. angle from vertical)
  • The laser cut hexagonal safety mesh maximizes light transmission and is tough enough to withstand location abuse

Warranty Information

This product has a limited warranty of 12 months for parts and 12 months for labor.

Product Documents

User Manual

Key Features

  • Pole-operated fixture offering versatility in light placement and movement
  • Part of the innovative True Blue Series, featuring over 30 technological improvements
  • Unique cross cooling system reduces lamp housing and lens temperatures, enhancing durability
  • Capable of projecting a 2.8' diameter beam of 409 foot-candles from a distance of 20'
  • Provides a 48 foot-candle, 20.4' diameter beam at full flood from the same distance

What's in the box:

  • ARRI T1 Location 1000W Fresnel
  • 3.0 ft. (1.0 m) Power Cable
  • ARRI 1 Year Warranty
