| Read Speed |
BD-R: 8X
BD-RE: 8X
BD-ROM: 8X
BD-R(DL): 8X
BD-RE(DL): 6X
BD-ROM(DL): 8X
DVD+R: 16X
DVD-R: 16X
DVD+RW: 12X
DVD-RW: 12X
DVD-ROM: 16X
DVD+R(DL): 12X
DVD-R(DL): 12X
DVD-ROM(DL): 12X
DVD-RAM: 12X
CD-R: 48X
CD-ROM: 48X
BDMV Playback: 4X
DVD Video Playback: 6X
VCD Playback: 16X
Audio CD Playback: 16X |
| Write Speed |
BD-R: 12X
BD-R(DL): 8X
BD-R(LTH): 4X
BD-RE: 2X
BD-RE(DL): 2X
DVD+R: 16X
DVD-R: 16X
DVD+RW: 8X
DVD-RW: 6X
DVD+R(DL): 8X
DVD-R (DL): 8X
DVD-RAM: 12X
CD-R: 48X
CD-RW: 24X |
| Writing Mode |
BD-RE: Sequential Write/Random Write
BD-R: Sequential Write
DVD+R & DVD+R (DL): Sequential Write
DVD-R & DVD-R(DL): Incremental Recording
DVD+RW: Random Write
DVD-RW: DAO/Restricted Overwrite/Incremental Recording
DVD-RAM: Random Write
CD-R/RW: DAO/TAO/SAO/Packet Write |
| Access time |
BD: 250 ms
DVD: 150 ms
CD: 150 ms |
| Interface |
SATA |
| Data Buffer |
8MB |
| OS Support |
Windows 7
Windows Vista
Windows XP |
| System Requirements |
Processor: Pentium D 945(3.4GHz) or higher
Memory: 1GB or more is recommended
HDD: 10GB or more
Graphics Card: NVIDIA GeForce 7600 GT or ATI X1600 series or above
Use HDCP Compatible display and VGA card to High Definition digital output |
| Software |
Cyberlink Power2Go
E-Hammer
E-Green |
| Disc Formats |
Audio CD, Video CD, CD-I, CD-Extra, Photo CD, CD-Text, CD-ROM/XA, Multi-session CD, DVD Video, BD video |
| Disc Diameters |
12cm/8cm |
| Mounting Orientation |
Vertical and Horizontal (+5Deg. - -5Deg.) |
| Power |
DC+5V ±5%,DC+12V ±10 % |
| Temperature |
Operating: 5 Deg.C to 45 Deg.C
Storage: -20 Deg.C to 60 Deg.C |
| Humidity |
Operating: 5 % - 85 % (Non-condensing)
Storage: 15 % - 90 % (Non-condensing) |
| Dimensions (L x W x H) |
170 x 146 x 41 mm (6.69 x 5.74 x 1.61") |
| Weight |
650 g (22.9 oz) |
