Aviom A16II Personal Monitoring Mixer for Monitor System

Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 212-741-0052

$599.00 List Price

Our Price

Free Shipping
Add to Wishlist In Stock

Protect your investment

About the Aviom A16II

The Aviom A-16II Personal Mixer is the industry standard solution for delivering high quality monitoring control directly to performers on stage and in the studio. Each A-16II Personal Mixer provides independent mix control of sixteen channels, including channel volume, pan/stereo spread and grouping, as well as master volume and tone controls. Additionally, each Personal Mixer can store and recall up to sixteen independent custom mix snapshots.

Individual channels, stereo pairs and channel groups can be soloed or muted. The Global Trim function can be used to decrease every channel's volume 6dB, providing additional headroom for mixing a selected channel. The TRS audio output from the A-16II can be connected to a range of devices, including wired in-ear monitors (IEMs), transmitters for wireless IEMs, headphones, powered monitors and power amps. The A-16II features unique high voltage and high current output circuitry which auto-detects stereo and mono connections.

Audio is delivered to the A-16II from a Pro16 input module or console card over a single Cat-5e cable, using Aviom's ultra-fast A-Net Pro16 technology. A-Net provides plug-and-play operation, long cable runs (up to 500ft/150m between devices) and sub-millisecond transmission of 24-bit digital audio. Power can be supplied to the A-16II through an external DC power supply or over the Cat-5e cable, using an A-16D or A-16D Pro A-Net Distributor. Personal Mixers can be daisy-chained (with external DC power supplied locally) or connected in parallel using an A-Net Distributor. A-16II Personal Mixers can be used in virtually any combination with other Pro16 devices, including the rack-mounted version of the Personal Mixer, the A-16R.

Aviom A16II Includes

  • Aviom A16II Personal Monitoring Mixer
  • External DC Power Supply
  • Category 5 Cable
  • System Owner's Manual
  • Aviom 1 Year Limited Warranty

Aviom A16II Features

  • 16-Channel remote personal monitoring headphone or line mixer with individual channel select buttons
  • 16 User Preset memory locations
  • Dedicated memory Recall and Group buttons
  • High gain headphone or line level output, low, imperceptible 880 micro-second latency from analog in to analog out
  • 24-Bit D/A conversion
  • True stereo mixing with adjustable panning; 5-segment LED readout for Pan control
  • Master Volume control, dedicated channel Volume control with 12-segment LED level readout
  • Global Trim 6 dB level attenuator function
  • Master Treble and Bass tone control knobs
  • Dedicated mute and solo buttons
  • Desktop/music stand surface mounting or mic stand mounting with optional stand adapter
  • Multi-voltage power supply support for international use

Aviom A16II Specifications

Audio Output 1/4-inch TRS stereo, headphone or line level
Line/Headphone TRS Output Tip: Audio Left; Ring: Audio Right; Sleeve: Ground
Auto-detects mono plugs
A-Net Input/Output 1 A-Net input, 1 A-Net output; Category 5 (RJ45 connector)
Digital to Analog Conversion Bit Depth 24 bit
Signal to Noise Ratio (Referenced to 0dB) -103dB
Latency <0.880 msec (measured from analog input to analog output)
Pro16 A-Net Uses unshielded Cat-5e UTP (or better) cable; maximum 500ft (150m) between devices
Tone Controls Treble +/-12dB at 9kHz shelving
Bass +/-12dB at 160Hz shelving
Maximum Levels (RMS) Line/Headphone outs: 1.0 watt at 100 ohms
Impedance Line/Headphone outs: 32 ohms
Power Supply External, DC, universal switching type
Input Voltage 100-240 volts, 50/60Hz, 30VA
Output Voltage 18-24 VDC, 0.5 amp
Plug Size 2 mm
Dimensions (W x D x H) 10.75" x 5.6" x 2.25" (273 x 142.2 x57.5 mm)
Weight 3.4 lbs. (1.54 kg)
