| Flash energy |
3200 J |
| F-stop at 2 m 100 ISO, reflector P70 |
90 2/10 |
| Flash duration t 0.1 (t 0.5) |
1/80 - 1/6000 s
(1/240 - 1/10 000 s)
Flash duration and energy automatically regulated for optimum color temperature. Flash duration can be preselected. |
| Charging time (100% of selected energy) |
(120 V) 0,04 - 3,2 s
(100 V) 0,04 - 4,4 s
Can be switched to slow charging mode for low amperage power outlets |
| Ready display |
Visual and audible (can be switched off); signals when 100% of selected energy is reached. |
| Lamp base connections |
2 main connections with flash cut-off and 1 reserve connection |
| Power output distribution |
Symmetrical and variable asymmetrical. |
| Controls |
Illuminated silicone keyboard, resistant to dust and scratches. Wireless remote control with infrared Servor d. |
| Control range |
6 7/10 f-stops for main connections, 4 f-stops for reserve connection in 1/10 or 1/3 f-stops interval. Display simultaneously in joules and f-stops, joules switchable to percentage. |
| Color Temperature |
CTC-technology (Color Temperature Control) for constant or deliberately variable color temperature with broncolor FCC (Flash Color Chronoscope) |
| Modelling light |
Halogen max. 3 x 300 W at 100-120 V
Proportional to flash energy and "full" and "low" settings.
Proportionality adjustable to other broncolor power packs, compact units and their various output levels. |
| Flash release |
Manual release button, photocell (can be switched off)
infrared receiver (can be switched off), sync cable, FCM
2, FCC, IRX2, IRQ, Transmitter RFS |
| Remote control |
With integrated 10 channel RFS interface (Radio Frequency System) for the remote control of the unit by radio via transceiver RFS from PC or Macintosh computer. Each channel (Studio) can control up to 15 units.
With IR-manual remote control Servor d for the control of the main functions of the Grafit A. |
| Operational distance outdoors |
Up to 50 m |
| Operational distance in closed rooms |
Up to 30 m |
| Range |
Up to 300 m |
| No. of sync sockets |
1 (instead of the second sync socket there is the radio antenna.) |
| Stabilized flash voltage |
+/- 0,5% |
| Standards |
EC standard 73/23, UL 122
ERM EN 300 220-1,-3
EMC EN 301 489-1,-3
EN 60950
EN 50371
FCC Part 15 |
| Lamp bases compatibility |
Pulso 2, F2, 4, F4, 8, Pulso Twin, Pulso G
Primo, Picolite, Mobilite
Ringblitz, Pulso-Spot 4 Universal lamp base with RT plug |
| Remote control compatibility |
Transceiver RFS, Servor d, Servor e, Servor 3, Servor 2
(without additional functions) |
| Remote release compatibility |
Transmitter RFS
IRX2, IRX, IRS-E
IRQ, FCM 2, FCC, IRS
IRI, FM |
| Power requirements |
110-120 V/60 Hz, switchable to 230 V/50 Hz, current consumption 15 A. |
| Dimensions |
288x180x407,5 mm |
| Weight |
11 kg |
