| Flash energy |
600 J (100 V: 500 J) |
| f-stop at a distance of 2 m / 6.6 feet |
(100 ISO, reflector P50 // P70) 45 5/10 // 32 5/10 (100 V: 45 2/10 // 32 2/10) |
| Flash duration t 0.1 (t 0.5) |
1/420 s (1/1500 s) with mains voltage 110 - 240 V
with mains voltage 100 V: about 20 % longer |
| Charging time |
230 V / 50 Hz: 0.4 - 1.4 s
120 V / 60 Hz: 0.4 - 1.9 s
100 V / 50 Hz: 0.4 - 3.0 s
Can be switched to slow charge mode |
| Controls |
Illuminated digital display, LED display as well as dust and scratch-proof, illuminated silicone keyboard |
| Control range of flash energy |
(100 V: 1/3 f-stop less) over 4 f-stops in 1/10 increments (1:16);
can be switched to 5 f-stops (1:32) |
| Modelling light |
Halogen max. 300 W
Proportional to flash energy as well as "full"and "low" settings. Proportionality adjustable to all broncolor flash systems and the various output levels. |
| Flash release |
Manual release button, photocell and infrared receiver (can be switched off), sync cable, FCM 2, FCC, IRX2. |
| Ready display |
Visual and audible (can be switched off), signals when 100% of selected energy is reached |
| Flash monitoring |
Visual: Dim or boost function of the modelling light during charging
Audible: buzzer |
| Number of sync sockets |
2 |
| Stabilized flash voltage |
+/- 1.5 % |
| Cooling |
Fan |
| Compatibility |
Light shaper: all broncolor light shapers
Remote release: IRX2, FCM2 |
| Standards |
100-120 V / 50-60 Hz: 10 A
Standards EC standard 73/23, UL 122 |
| Power requirements |
200-240 V / 50-60 Hz: 6 A |
| Dimensions (L x W X H) |
286 x 154 x 194 mm / 11.2 x 6 x 7.6 inch |
| Weight |
3.3kg / 7.3 kg |
