| Attachment (Head) |
1/4'' screw with VHS pin attachment type |
| Attachment (bottom) (Head) |
3/8" female thread attachment type |
| Color (Head) |
black color |
| Front tilt (Head) |
-75° / +90° tilt range |
| Height (Head) |
3.78 in |
| Independent pan lock (Head) |
yes |
| Independent tilt lock (Head) |
yes |
| Load capacity (Head) |
5.51 lbs |
| Material (Head) |
aluminum |
| Maximum working temperature (Head) |
-10 |
| Minimum working temperature (Head) |
60 |
| Pan bar - positions (Head) |
1 number |
| Pan bars included (no.) (Head) |
1 number |
| Pan drag (Head) |
fluid cartridge with fixed drag |
| Panoramic rotation (Head) |
360 ° |
| Plate type (Head) |
200PL-14 |
| Quick release (Head) |
yes |
| Secondary safety system (Head) |
yes |
| Tilt drag (Head) |
fluid cartridge with fixed drag |
| Center column (Tripod) |
rapid |
| Closed length (Tripod) |
24.21 in |
| Color (Tripod) |
black background Color |
| Column cross-section (Tripod) |
three-faceted |
| Column tube diameter (Tripod) |
28mm |
| Leg angles (Tripod) |
23°. 47°. 66°. 89° |
| Leg cross-section (Tripod) |
round |
| Leg sections (Tripod) |
3 number |
| Legs tube diameter (Tripod) |
29.2 . 24.8 . 20.4 mm |
| Load capacity (Tripod) |
17.64 lbs |
| Material (Tripod) |
carbon fiber legs. aluminum column + magnesium. aluminum castings |
| Working height (Head) |
3.78 in |
| Weight (Head) |
1.15 lbs |
| Maximum height (Tripod) |
69.68 in |
| Maximum height |
53.54 in (with center column down) (Tripod) |
| Minimum height (Tripod) |
22.44 in |
| Weight (Tripod) |
3.92 lbs |
| Warranty |
Bogen 2 year limited warranty |
