| Magnification |
3x - 9x |
| Objective / Field of View |
40mm / 38.5' (11.7m) @ 3x at 100 yds.(100m), 12.8' (3.9m) @ 9x at 100 yds.(100m). |
| Main (Center) Tube Diameter |
25.4mm, 1" |
| Objective Tube Diameter |
Not Specified by Manufacturer |
| Eyepiece Tube Diameter |
Not Specified by Manufacturer |
| Lens Coatings |
Fully multi-coated optics |
| Reticle |
DOA 600 |
| Reticle Image Plane (Magnifying) |
Reticle in Second Focal Plane. |
| Twilight Performance |
91% Light Transmission |
| Exterior Finish |
Matte Black |
| Windage & Elevation Adjustments (MOA) |
1/4-M.O.A., 7mm, Per Click |
| Maximum Adjustment |
60 MOA Elevation & Windage Adjustment |
| Exit Pupil |
13.3mm @ 3x, 4.4mm @ 9x |
| Eye Relief |
4.0", 101.0mm |
| Parallax Correction Control |
Not Specified by Manufacturer |
| Diopter Adjustment |
Not Specified by Manufacturer |
| Material |
Aluminum |
| Nitrogen Filled |
Yes, Dry Nitrogen Filled |
| Waterproof / Fogproof |
Yes |
| Length |
11.89", (302.0mm) |
| Mounting Length |
5.5", 140mm |
| Weight |
13.76 oz., 390g. |
| Special Features |
91% Light Transmission
Euro Style Windage & Elevation Controls
Molded, Intergrated Saddle |
