| Focal Length (Nominal) |
5.5 - 88mm |
| F number (Nominal) |
F1.6 - 2.6 |
| Angle of View (Nominal) |
Wide 47° 09' x 36° 14' (diagonal angle: 57° 13')
Tele 3° 07' x 2° 20' (diagonal angle: 3° 55') |
| Minimum subject distance |
From the edge of the lens
Wide 20mm (3/4 in)
Entire Zoom range & Mid 1m (3ft 3 3/8in)
Tele 1m (3ft 3 3/8in) |
| Minimum subject range |
Wide 54 x 40.5 mm (diagonal angle 67.5mm) (2 1/8 x 1 5/8 in(2 5/8))
Tele 73 x 54.5 (diagonal angle: 91mm) (2 7/8 x 2 1/8 (3 5/8)) |
| Lens configuration |
10 groups 12 elements (2 aspherical elements) + vari-angle prism + protection glass |
| Zoom system |
Power Zoom, manual zoom via zoom ring |
| Zooming speed |
Multi-level variable speed (16-stage, approx 1.7 - 60 sec.) Single speed (approx. 30 sec.: via wireless controller) |
| Aperture |
6-blade iris type. Automatic (operation from the camera) only. |
| Mount |
Compliant with XL mount system |
| Filter Screw diameter |
72mm dia. P0.75 (2 7/8 in dia.) |
| Focus System |
TV-AF (video signal AF) compliant, a manual focus ring |
| Subject distance |
20mm - infinity (Wide), 1m - infinity (Entire Zoom Range & Mid), 1m - infinity (Tele) |
| `Image Stabilizer |
Super Range optical image stabilizer |
| Detecting method |
Angular speed detection ON-OFF switch equipped. Turned off when image stabilizer isn't used or when no lens is mounted. |
| ND filter |
Built-in filter detachable with a switch, equivalent to 5 apertures (approx. 3.1% transparency) |
| Color |
Pearl White |
| Hood |
Bayonet hood (edge of the lens) for the lens |
| Power consumption |
500 mA or less |
| Size |
Approx 92 (max dia) x 134 mm (Approx 3 5/8 dia x 5 1/4in) |
| Weight |
Approx 650 g ( approx 1 lb 6 7/8oz) |
