| Video System: Recording Medium |
Dual Flash Memory (8Gb internal + SDHC card slot) with Relay Recording (internal memory to card) |
| Max Recording Time |
Variable total, depending on memory card size
Internal memory: 3hrs 00mins
32Gb SDHC card: 12hrs 15mins |
| CCD: Type |
1/4 type CMOS |
| Total Pixels |
3.89 megapixel |
| Effective Pixels: Movie |
2.99 megapixels |
| Effective Pixels: Still |
3.31 megapixels (4:3 mode) |
| Filter |
RGB Primary Color Filter |
| Lens: Advanced Zoom |
18x |
| Optical Zoom |
15x |
| Digital Zoom |
300x |
| Digital Tele-Converter |
No |
| Focal Length |
4.1-61.5mm |
| 35mm Equivalent Focal Length |
Movie: Approx 39.5-711 mm
Still: Approx 39.5-592.5 mm |
| Maximum Aperture |
f1.8 to f3.2 |
| Minimum Focusing Distance |
10mm |
| Image Stabilizer |
Dynamic Optical Image Stabilizer, Powered Optical Image Stabilizer mode |
| Filter Diameter |
37mm |
| Wide Attachment |
Yes (optional WD-H37 II) |
| Image Processor |
DIGIC DV III |
| Face Detection Technology |
Yes |
| LCD Screen Size |
6.8cm (2.7") widescreen Multiangle Vivid LCD |
| Pixels |
211,000 pixels |
| Touch-Screen LCD |
Yes |
| Manual Adjustment |
Brightness, backlight |
| Temporary Underscan |
No |
| Minimum Illumination: Minimum Lux. |
Approx. 0.4 lux (Low Light Mode) |
| Night Mode |
Yes |
| Auto Gain Control Limit Adjustment |
Yes |
| Focus Auto/Manual |
Yes / Yes |
| Control |
Auto: Face Priority AF/Instant AF/TV AF
Manual: Touch panel |
| Manual Focus Assist |
Yes (Magnification, Face Assist) |
| AE Mode: Smart Auto |
Yes (31 scene) |
| Program AE |
16
Auto, P, Av, Tv, CINE, Portrait, Sports, Snow, Beach, Sunset, Night, Low Light, Spotlight, Fireworks, Underwater, Surface |
| Zebra |
No |
| Backlight Compensation |
Yes |
| White Balance: Type |
TTL |
| Auto |
Yes |
| Set/Preset |
Yes (Daylight, Shade, Cloudy, Tungsten, Fluorescent, Fluorescent H) |
| Shutter Speed: Maximum |
1/2000th sec. |
| Slow |
1/2 sec. |
| Digital Effect: Fade |
Auto Fade, Wipe |
| Effect |
Black & White, Sepia |
| Image Quality Adjustment: Image Effects |
Vivid, Neutral, Low Sharpening, Soft, Skin Detail, Custom |
| Custom Functions |
Brightness, Contrast, Sharpness, Color Depth |
| Custom Key |
No |
| Still Image: Capture Image Size |
2304 x 1296, 2100 x 1575, 1600 x 1200, 848 x 480, 640 x 480 |
| Continuous Shooting Mode |
Yes (Normal and High-speed) |
| Auto Exposure Bracketing |
Yes |
| Simultaneous Photo Recording |
Yes |
| Selecting AF Frame Function |
Yes |
| Histogram |
Yes |
| Photo Button |
Yes |
| Photo Burst |
Yes |
| Self Timer |
10 sec
2 sec with wireless remote |
| Recording Mode: LP Mode |
5 recording quality modes, MXP: 1920x1080, 24Mbps, XP: 1920x1080, 17Mbps, XP+: 1440x1080, 12Mbps, SP: 1440x1080, 7Mbps, LP: 1440x1080, 5Mbps |
| Progressive Shooting Mode |
Yes (25p) |
| CINE Image Mode |
Yes |
| X.V.Color |
Yes |
| Video Snapshot |
Yes |
| Dual Shot |
Yes |
| Pre Rec |
Yes |
| Color Bars and Test Tone |
No |
| Search: Still Image |
No |
| Date |
Yes (date select, calendar, timeline, Face Timeline, Face Jump, 3D Flip) |
| Memory Card: Multi Media Card |
No |
| Secure Digital Card |
SD / SDHC |
| Movie Recording |
Yes |
| Internal Data Transfer |
Movie: Yes (internal memory to card), Stills: Yes (internal memory to card) |
| Audio: System |
Dolby Digital 2ch (AC-3 2ch), 5.1ch surround sound (via Optional SM-V1 microphone) |
| Manual Rec. Level Control |
Yes |
| Audio Dubbing |
No |
| Terminal: Headphone |
Yes |
| Microphone |
No |
| USB |
Yes (USB 2.0 Hi Speed out only) |
| DV |
No |
| Direct Print |
Yes |
| Analogue-in |
No |
| AV |
Yes (out only) |
| S-video |
No |
| Component |
Yes (out only) |
| HDMI |
Yes (HDMI Mini Connector: v1.3, CEC supported, out only) |
| LANC |
Yes (optional RA-V1 adaptor) |
| Built-in Charger |
Yes |
| Quick Start |
Yes (using LCD screen) |
| Accessory Shoe |
Yes (mini Advanced Accessory Shoe) |
| Built-in Video Light |
Yes (white LED) |
| Built-in Flash |
Yes |
| PC Connectin:Digital Video Solution Disk |
Yes (v34) |
| DV Network Solution Disk |
No |
| Application Software |
Yes (PIXELA ImageMixer 3 SE, Music Transfer utility) |
| USB Cable |
Yes |
| Easy Web Upload |
Yes |
| HD->SD conversion |
Yes |
| Wireless Controller |
Yes |
| Battery Pack: Type |
Lithium Ion |
| Intelligent Battery System |
Yes |
| Battery Included In The Kit |
BP-808 |
| Max Recording Time (Included Battery) |
1hr 40mins |
| Quick Charge |
No |
| Long Life Battery |
BP-827 |
| Longer Recording Time |
5hr 10mins |
| Dimensions: W x H x D |
68mm x 60mm x 123mm |
| Weight |
Approx. 320g |
