| Standard Definition or High Definition |
High Definition |
| Power Consumption |
2.8W (LP Mode, LCD set to normal brightness) |
| Television System |
NTSC |
| Video Recording system |
MPEG4-AVC / H.264 |
| Image Sensor |
1/5.5-inch CMOS, RGB Primary Color Filter |
| Total Pixels |
Approx. 2.39 Megapixels |
| Effective Pixels: Video |
Approx. 1.56 Megapixels (1664 x 936)
Dynamic IS ON: Approx. 1.04 Megapixels (1360 x 765) |
| Effective Pixels: Photo |
16:9 Approx. 1.56 Megapixels (1664 x 936)
4:3 Approx. 1.73 Megapixels (1520 x 1140) |
| Maximum recording time |
32GB internal flash drive:
LP (5Mbps) 12 hours 15 minutes
SP (7Mbps) 9 hours 35 minutes
XP+ (12Mbps) 5 hours 45 minutes
FXP (17Mbps) 4 hours 10 minutes - Allows 1920 x 1080 Full HD Recording |
| Lens: Zoom Ratio |
20x Optical/400x Digital |
| Lens: Focal Length |
f-3.0 - 60mm (35mm equivalent 40 - 800mm) |
| Lens: Zoom Speed |
Variable / 3 Fixed Zoom Speeds |
| Lens: Max. F/Stop |
f/1.8-3.6 |
| Focusing System |
Instant AF, Face Priority AF, TTL (through the lens) |
| Manual Exposure |
Yes |
| Programmed AE |
Smart Auto, P, Cine*, Portrait, Sports, Snow, Beach, Sunset, Night Scene, Low Light, Spotlight, Fireworks |
| Max Shutter Speed |
Movie: 1/2000, Still image: 1/500 |
| Minimum Focusing Distance |
10mm (wide) / 1m (tele) |
| White Balance |
Auto, Daylight, Shade, Cloudy, Tungsten, Fluorescent H, Fluorescent, Manual |
| Frame Rate |
60i, 24p Progressive (records at 60i), 30p Progressive (records at 60i) |
| Minimum Illumination |
0.4 lx (Low Light mode) |
| Image Stabilization |
Electronic: Dynamic Image Stabilization/Standard Mode (Dynamic OFF) |
| Filter Diameter |
None |
| Viewfinder |
None |
| LCD Screen |
2.7-inch Widescreen color LCD (Approx.112,000 dots) |
| Flash |
None |
| Recording Media |
Internal flash drive (32GB) or SD memory card** |
| USB Terminal |
USB 2.0 Hi-Speed |
| Video Terminal |
component (output), composite (output) |
| Audio |
Dolby Digital 2 channel (AC-3) |
| Accessory Shoe |
None |
| Supplied Video Editing Software |
Pixela ImageMixer 3SE |
| HDMI Terminal |
HDMI Mini Connector (output), CEC and x.v.Color supported |
| Microphone Terminal |
3.5 mm stereo mini-jack |
| AV Mini Terminal/Headphone Terminal |
3.5 mm 4 pole mini-jack (video/audio output only) |
| Dimensions |
(W x H x D) Approx. 2.4 x 2.5 x 4.9in. (60 x 64 x 124mm) |
| Weight (w/o battery pack & memory card) |
Approx. 9.5 oz. (270g) |
| Weight (fully loaded) |
Approx. 11.5 oz. (325g) (including BP-2L5, memory card and grip belt) |
