| Imaging Device |
0.55" Reflective LCD Panels (LCOS) x 3 |
| Aspect Ratio |
4:3 |
| Native Resolution |
SXGA+ (1400 x 1050) |
| Brightness |
3000 Lumens |
| Uniformity |
88% |
| Contrast |
900:1 |
| Digital Keystone (Vertical) |
± 20 degrees (Auto/Manual) |
| Digital Keystone (Horizontal) |
N/A |
| Projection Lens |
F1.95 - 2.6, f=16.6 - 24.8 mm
10:0; Fixed |
| Zoom |
1.5x Powered, 12x Digital |
| Focus |
Powered (Auto/Manual) |
| Screen Size |
40"-300" |
| Throw Distance |
3.9 - 29.9 ft. |
| Throw Ratio |
1.48 - 2.18:1 |
| Image Mode |
Standard, Presentation, Movie, sRGB, Photo |
| Color Adjust |
Dynamic Gamma, 6-Axis (RGBCMY) Color Adjustment |
| Wall Correction |
Auto / Manual |
| Mounting |
Ceiling / Rear / Ceiling and Rear |
| Tilt Angle |
Adjusting feet up to 10 degrees |
| Scanning Frequency |
H:15~75 kHz , V:50~85 Hz Dot clock: 170 MHz or less |
| Analog PC Input |
UXGA / SXGA+ / WXGA / SXGA / XGA / SVGA / VGA |
| Digital PC Input |
SXGA+ / SXGA / WXGA / XGA / SVGA / VGA |
| Video/S-Video Input |
NTSC / PAL / SECAM / NTSC4.43 / PAL-M / PAL-N |
| Component Input |
1080p / 1080i / 1035i / 720p / 576p / 480p / 576i / 480i |
| Digital Video Input |
HDMI: 1080p / 1080i / 720p / 576p / 480p |
| (Input) DVI-I 29pin |
Digital PC input / Analog PC input / Digital video input |
| (Input) D-Sub 15pin |
Analog PC input / Component input |
| (Input) RCA x1 |
Video Input |
| ((Input) Mini DIN 4pin |
S-Video input |
| (Input) 5BNC |
Analog PC input / Component input |
| (Input) RJ-45 |
Network input x 1 |
| (Input) Stereo Mini Jack |
Stereo audio output x 3 |
| (Output) D-Sub 15pin |
Analog PC out |
| (Output) Stereo Mini Jack |
Stereo audio output x 1 |
| Built-in Speaker |
1W (Mono) |
| Control Terminal |
D-sub 9pin |
| Lamp Type |
230W NSH (AC) |
| Lamp Life (Normal/Quiet) |
2000 / 2500 Hours (Normal/Quiet) |
| Fan Noise (Normal/Quiet) |
31 (quiet) / 35 (normal) dB |
| Power Consumption(Normal/Quiet/Stand-By) |
330W (normal) / 270W (quiet) / 15W (stand-by) |
| Power Voltage |
AC 100 ~ 240V, 50/60Hz |
| Temperature Operating |
41° to 95° F (5° to 35° C) |
| Temperature Storage |
104° to -22° F (60° to -30° C), 5%RH ~ 90%RH |
| Dimension (WxHxD) |
13.0" x 4.8" x 13.4" (332 x 121 x 340mm) |
| Weight |
11.5 lbs (5.2 kg) |
| Warranty |
Canon 3 years parts & labor and 120 days lamp warranty |
