| Imaging Device |
0.7" Reflective LCD Panels (LCOS) x 3 |
| Aspect Ratio |
16:10 |
| Native Resolution |
WUXGA (1920 x 1200) |
| Brightness |
4000 Lumens |
| Uniformity |
88% |
| Contrast Ratio |
1000:1 |
| Projection Lens |
3 optional interchangeable lenses: RS-IL01ST, RS-IL02LZ, RS-IL03WF |
| Color Adjust |
Levels / Balance / Temperature / RGB Gain / RGB Offset / 6-Axis Color Adjustment / Memory Color Correction |
| Wall Correction |
Greenboard |
| Mounting |
Ceiling / Rear / Rear-Ceiling / Upwards / Downward |
| Tilt Angle |
Adjustable feet up to 6 degrees |
| Scanning Frequency |
H: 15-75 kHz, V: 50-85 Hz; 162 MHz or less |
| Analog PC Input |
WUXGA / UXGA / WSXGA+ / SXGA+ / WXGA+ / WXGA / SXGA / XGA / SVGA / VGA |
| Digital PC Input |
WUXGA / UXGA / WSXGA+ / SXGA+ / WXGA+ / WXGA / SXGA / XGA / SVGA / VGA |
| Component Input |
1080p / 1080i / 720p / 576p / 480p / 480i |
| Digital Video Input |
1080p / 1080i / 720p / 576p / 480p |
| (Input) Stereo Mini Jack |
Audio Input x2 |
| (Output) Stereo Mini Jack |
Audio Output x1 |
| Built-in Speaker |
5W |
| Control Terminal |
D-sub 9pin: RS-232C Network: RJ-45 |
| Lamp Type |
330W NSH (AC) |
| Lamp Life |
3000 (normal) / 4000 (quiet) Hours |
| Sensor |
Wireless Infrared (Front / Back) |
| Fan Noise (Quiet/Normal) |
36 / 39 dB |
| Power Consumption |
Normal/Quiet/Stand-By: 450W / 390W / 0.5W (with LAN off) |
| Power Voltage |
AC 100 - 240V, 50/60Hz |
| Temperature Operating |
41deg. to 95deg. F (5deg. to 35deg. C) |
| Temperature Storage |
-22deg. to 104deg. F (-30deg. to 60deg. C), 5 - 90% RH |
| Dimension (W x H x D) |
Without lens: 14.96" x 5.90" x 16.92" / 379.98 x 149.86 x 429.77 mm |
| Weight |
Without lens: 18.7 lbs / 8.48 kg |
