Denon

Denon DRA-697CIHD Premier AM/FM/FM Multi-Source/Multi-Zone Stereo Receiver with HD Radio

SKU: CCSDRA697CIH MFR: DRA-697CIHD
Please note: This item is currently back-ordered by the manufacturer. Although we have no estimated time of arrival for this item, you can order it now and it will ship as soon as it arrives. Your card will only be charged once item is shipped.
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 212-741-0052

Our Price

$899.00
Free Shipping
Qty:

Add to Wishlist

Protect your investment

About the Denon DRA-697CIHD

The DRA-697CIHD receiver will shine as the core to your high end Hi-Fi stereo multi-room audio system. Equipped with many new features including HD Radio, it can handle almost any configuration combination. Its two source three zone capability allows you to run multiple sources to multiple areas at the same time with pure clean sound. With the HD tuner as a second tuner source, regular AM/FM can be listened to in one zone and HD Radio can be listened to in another zone. Being 4 ohms stable, it can handle the most demanding speakers, yet deliver smooth fidelity. Custom integration is no problem either as this enhance receiver has all the connections an installer needs to integrate to third party control systems.

Denon DRA-697CIHD Includes

  • Denon DRA-697CIHD AM/FM/FM Stereo Receiver
  • Operating Instructions
  • Remote Control (RC-1066)
  • 2 x AAA Batteries
  • AM Loop Antenna (for HD Radio Broadcasting)
  • FM Indoor Antenna (for HD Radio Broadcasting)
  • Denon 2 Years Limited Warranty

Denon DRA-697CIHD Features

  • With 100W of power per channel (at 8 ohms, 20 Hz - 20 kHz, 0.08% THD), the DRA-697CIHD delivers solid, reliable audio performance even when driving both A and B speaker systems at the same time
  • The circuit handling low-level signals has been divided into separate blocks to ensure that influences from these signals on each other are held to an absolute minimum
  • The new chassis design, known as the Signal Level Divided Construction (SLDC), preserves the purity of the signal, allowing it to be reproduced with much greater fidelity and clarity
  • The DRA-697CIHD has 2 source / 3 zone capability. Dedicated multi-room outputs, with volume level adjustment via remote control, are provided for connection to powered speakers or an additional amplifier in Zone 2 and Zone 3
  • Custom Integrated: RS232C serial command control
    Remote in/out IR command control
    Discrete power on/off command
    IR off, panel lock mode
    Assignable +12V trigger
  • The DRA-697CIHD is equipped with HD radio tuner, let the DRA-697CIHD use its dual tuner capability in the future
  • Pre-memory remote for main zone can control TV, SAT, Cable and zone remote can be switched for zone 2 or zone 3 to control power, function, volume control
  • Allows you to select a video source and then select an alternate audio input source, ideal for simulcasting, as well as watching TV sports programs while listening to radio commentary
  • Supports iPod playback when connected to the DRA-697CIHD
  • Denon's original Control Dock for iPod (sold separately) is connected to the dedicated control terminal of the DRA-697CIHD. The iPod can also be controlled via the remote controller supplied with the DRA-697CIHD
  • Optional XM Mini-Tuner and subscription are required
  • FM stations can be searched by the tuner and automatically stored in the preset memory up to 56 stations, ideal for locales with many FM stations
  • Pure Direct Mode, for the pure enjoyment of music in high-quality sound
  • Fast up/down manual tuning
  • Manual step tuning
  • Last-channel-tuned memory
  • Loudness Function
  • Tone Defeat
  • Muting Function via remote controller
  • A/B Speaker Switching
  • Last Function Memory
  • 3 AC outlets
  • Detachable AC power cord

Denon DRA-697CIHD Specifications

Surround RMS Power 100W + 100W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Freq. Response (Rec/Repro) 10 Hz - 100 kHz +0 dB, -3 dB (at 1W)
Input Sensitivity Phono: 2.5mV/47 kohms
CD, CD-R/Tape, DVD/VDP, VCR, V.Aux: 200mV/47kohms
Output Level Zone2, Zone3: 1.2V/47 kohms
THD 0.009% (-3dB at rated output, 1 kHz)
Deviation RIAA: +/- 0.5dB (20Hz - 20kHz)
Tone Control Treble: ±10 dB at 10 kHz, Bass: ±10 dB at 100 Hz
HD Radio: Tuning frequency range 87.5 - 107.9 MHz
HD Radio: Usable sensitivity 1.0 uV (11.2 dBf)
HD Radio: S/N ratio (A-weighted) Mono: 77 dB, Stereo: 72 dB, HD: 80 dB
HD Radio: Total harmonic distortion Mono: 0.15%, Stereo: 0.3%, HD: 0.005%
HD Radio: Frequency response 20 Hz - 15 kHz (+0.5, -1.0 dB)
HD Radio: Stereo separation 43 dB (1 kHz)
AM Frequency Range 520 - 1710 kHz
AM: Usable sensitivity 18 uV
AM: S/N HD: 80 dB
AM: Total harmonic distortion HD: 0.005%
Remote Control RC-1066
Remote Control Batteries R03/AAA Type (two batteries)
Power Requirements AC 120 V, 60 Hz
Power Consumption 4.2 A
Dimensions (WxHxD) 17.1 x 6.7 x 16.4" (434.3 x 170.18 x 416.6mm)
RC-1066 Remote Control: 2.1 x 4.5 x 1" (53.34 x 114.3 x 25.4mm)
Weight 23.1 lb (10.5kg)
RC-1066 Remote Control: 2.8 oz (79.38 g)
