| Video Standards |
HD-SDI, SMPTE 292M; HD-SDI 3G, SMPTE 424M; HD-SDI Dual-Link, SMPTE 372M |
| Video Formats |
1080p23.98/24/25/29.97/50/59.94;
1080i50/59.94;
720p23.98/25/29.97/50/59.94/60;
2048x1080p23.98/24 |
| Video I/O |
Four BNCs, (2 Input, 2 output, with individual power-down options), One HDMI (Type C) Output |
| Playback Control |
Play, Rewind, Fast-Forward, Pause and Step Control |
| S-Log, Log-C Support |
Support for S-Log, Log-C with user programmable 1D LUTs, LUTs can be applied to either SDI output |
| Media |
Two Slots for 1.8" Solid State Drives (SSD), Hot-Swappable, 256GB / 512GB sizes |
| SSD Performance |
260 MBytes/Sec Write, 415 MBytes/Sec Read, 6Gbps SATA Interface |
| Transfer Station |
1.8" SSD to 6Gbps eSATA transfer station |
| Built-In LCD Monitor |
5" high brightness LCD, sunlight viewable, 800 cd/m2, 800 x (RGB) x 480 Pixels, 24-Bit, 900:1 True Contrast, Wide 85deg. Viewing Angle (IPS Technology), Color Calibrated at Factory |
| Menu System |
Touch Sensitive menu system with user-defined presets and customizable level of on-screen data |
| Timecode |
HD-SDI Embedded (SMPTE RP-188) or LTC via the remote control option |
| Digital Audio I/O |
HD-SDI Embedded 4-Channels, uncompressed, 24-Bit, 48K; 16-Channel in future firmware |
| Analog Audio Output |
3.5 mm output jack, headphone or consumer line level, support to monitor any channel pair |
| 3D - Dual Stream |
Left and Right Video Streams recorded as individual files, in full uncompressed
Vertical Flip, Horizontal Flop, for either/both streams
Individual output of each stream or Combine: Side by Side, Line by Line, Anaglyph, 50/50 Composite
Simultaneous output in multiple formats (ie Side by Side and 50/50 Composite) |
| Remote Control |
Wired Remote Control with Tally Light and LTC I/O |
| NLE Compatibility |
NLE Support planned for Avid, Final Cut Pro, Premiere, Vegas and Edius |
| Power Requirements |
6 to 19 Volts DC, 8 to 15 watts (active) / under 1 watt (power-save mode) |
| Environmental |
Operating: +50 to -20 deg.C
Storage: +75 to -40 deg.C |
| Dimensions |
5.4 x 4.5 x 1.1 inches (138 x 114 x 27 mm) |
| Weight |
1 lb (450 g ) |
