CalDigit
CalDigit 4 Bay HDElement 4TB Desktop External Raid Tower Expansion Unit
Mfr. Part: 756215 SKU: CDN756215
enlarge image
|
|
 |
| Please Note! This Special Order Item is Non Cancelable and Non Returnable. We Charge you when you place your order. Approximate arrival at Adorama 7-14 business days. |
|
|
Item Includes
CalDigit HDElement 4TB External Hard Drive Array - Mini SAS Cable x 1 - Drive Trays x 4 - Installation CD - Power Cord x 1 - CalDigit 1 Year Warranty
|
Description
The HDElement is the compact 4-bay hardware RAID storage. Each HDElement gives you flexibility of configuring your RAID on different RAID Levels such as RAID 0, 1, 5, 6, 50, 60 and JBOD. As your workloads increase it is easy to expand your storage capacity.
The unique, cross-platform technology is compatible with MAC OS X, Windows and Linux workstations. It supports a variety of software applications and have been validated by Matrox Video Group, Blackmagic Design and Media 100. |
Features
 |
Hardware raid: Powered by the CalDigit RAIDCard, the HDElement has a 100% hardware disk controller that comes with its own independent CPU |
|
Fast & safe: The HDElement is designed for both speed and protection. It supports RAID 0, RAID 1, RAID 5, RAID 6 and JBOD |
|
Flexibility: Users can configure multiple RAID Levels on different HDElements or even on different group of drives. This allows users to have different RAID protection on different workflow |
|
User friendly GUI: The HDElement uses an environment monitor processor to run all aspects of the system |
|
Powered by Intel XScale Core Processor: HDElement works in conjunction with CalDigit RAID that comes with a built-in Intel XScale Core Processor and 256 MB dedicated cache memory. It optimizes low power consumption, maximizes performance, accelerates data processing and adds protection to storage |
|
Active Sustained Transfer Technology (ASTT): Any highs (peaks) and lows (drops) during data transference are equalized by the Active Sustained Transfer Technology. It optimizes the best transfer size and timing between the RAID controller cache and the host machine |
|
Bootable: The HDElement is bootable. You have the ability to start up from HDElement if you have installed OS such as Mac OS, Windows, or Linux |
|
No More 2TB Limitation in Windows Platforms: Windows uses 32-bit block numbers in its lower storage stack. This effectively limits support for hardware RAID sets |
Specifications
| HDD size | 4TB |
| HDD support | SATA II 3.0Gb/s |
| Fan Design | Modular |
| Fan Outline Dimension | 92 x 92 x 25 mm |
| Fan Rated Voltage | DC 12.0 V |
| Fan Rated Current | 0.16 A + 10% |
| Fan Rated Power Consumption | 1.92 W + 10% |
| Fan Rotational Speed | 2400 R.P.M. +/- 10% |
| Fan Max. Airflow | 50.8 CFM (ft3/min) |
| Fan Noise Level | 33.0 dB (A) |
| Power supply | 200W Cool Swappable Power Supply with Fan |
| Full range | 100~240 VAC (+/- 10% tolerance) |
| Input frequency range | 47hz~63hz |
| Steady-state current | 4~2 amps maximum at any low/high range input voltage |
| Inrush current | 65/130 amps @ 110/220 VAC (at degrees ambient cold start) |
| Power factor correction | PFC can reach the target of 95% @115V, full load, following the standard of IEC 1000-3-2 |
| Operation Temperature | 0°C~60°C |
| Storage Temperature | -20°C~70°C |
| Operation Humidity | 5%~85%, Non-condensing |
| Storage Humidity | 5%~95% |
| OS | Windows XP, Vista, Mac OS X, Linux |
| Height | 9.65 inches (33.4 cm) |
| Width | 5.51 inches (15.2 cm) |
| Depth | 12.99 inches (32.6 cm) |
| Weight | 17.97 lbs (8.15 kg) |
| Warranty | CalDigit 1 year warranty |
| | |
|
|
|
|
|
|
|
|
|
|
