| Optical Design |
6" (150mm) Schmidt-Cassegrain |
| Focal Length |
1500mm F/10 |
| Optical Coatings |
StarBright XLT |
| Optical Tube |
Aluminum, metallic orange |
| Mount |
Single fork arm, altazimuth |
| Dovetail |
Quick release tube clamp |
| Hand Control |
Computerized |
| Eyepiece (mm) |
25mm E-Lux (60x) |
| Finderscope |
StarPointer |
| Diagonal |
Star diagonal, 1.25" |
| Tripod |
Pre-assembled steel |
| Included Software |
NexRemote & The Sky L1 |
| Software Features |
n/a |
| Camera Shutter Cable |
no |
| Power Supply |
8-AA batteries (user supplied) |
| Highest Useful Magnification |
354x |
| Limiting Stellar Magnitude |
13.4 |
| Resolution: Rayleigh (arc sec) |
.92 arc seconds |
| Dawes Limit (arc sec) |
.77 arc seconds |
| Light Gathering Power |
459x unaided eye |
| Field of View (degrees) |
.83º |
| Linear FOV (ft@1000 yds) |
43.8 ft. |
| Optical Tube Length |
16 inches |
| Telescope Weight |
21 lbs |
| Tripod Weight |
9 lbs |
| Computerized Hand Control |
Double line 16 character, liquid crystal display; 19 LED backlit buttons |
| Database |
40,000 Object, 400 user defined programmable objects, enhanced information on over 200 objects |
| Slew Speeds |
Variable rate, nine speeds |
| Ports |
RS-232, Aux, Camera Control |
| Tracking Rates |
Sidereal, Solar and Lunar |
| Tracking Modes |
Alt-Az, EQ North & EQ South |
| GPS Compatible |
CN-16 GPS accessory |
| Alignment Procedures |
SkyAlign, Auto 2-Star Align, 1-Star Align, 2-Star Align, Solar System Align |
