| Rack Size |
1U |
| Input Voltage |
120V |
| Input Frequency |
50Hz/60Hz |
| Maximum Input Current |
20A |
| Input Plug Type |
NEMA L5-20P |
| Input Plug Style |
Straight |
| Input Cord Length |
15' |
| Nominal Output Voltage |
120V |
| Overload Protection |
20A |
| Outlets - Total |
12 |
| Outlets - Front |
2 |
| Outlets - Rear |
10 |
| Outlet Type |
NEMA 5-20R |
| Output LED Indicators |
Power On(Green) Grounded (Green) |
| Surge Suppression |
1,800 Joules |
| Protection Modes |
N-H, N-G and H-G |
| Maximum Surge Current |
90,000 Amps |
| Maximum Surge Voltage |
6,000 Volts |
| Clamping Voltage |
N-H 400V, N-G 500V, H-G 400V |
| Response Time |
1 nanosecond |
| EMI/RFI Filtration |
Yes |
| Attenuation |
Up to 50dB |
| Style |
Rackmount, Vertical Rackmount, Under-Counter |
| Form Factors Supported |
1U rackmount, 0U vertical rackmount, undercounter installation supported |
| Cord Retention Tray/Cord Organizers |
Yes |
| Adjustable Mounting Brackets |
2 sets(L-short/L-long) |
| External Site Ground Pin |
Yes |
| Material of Construction |
Metal |
| Operating Temperature |
32 Deg.F to 95 Deg.F / 0 Deg.C to 35 Deg.C |
| Operating Humidity |
0% - 95% non-condensing |
| Maximum Operating Elevation |
10,000 ft / 3,000 m |
| Storage Temperature |
5 Deg.F to 113Deg.F / -15Deg.C to 45 Deg.C |
| Maximum Storage Elevation |
50,000 ft / 15,000 m |
| Certifications |
UL1363 UL1449 certified by ETL(USA), CSA C22.2 |
| Compliant |
ROHS Compliant |
| Dimensions (W x H x D) |
1.75 (1U) x 17.5 x 2.25" / 4.44 x 44.45 x 5.71 cm |
| Weight |
4.88 lbs / 2.21 kg |
