| UPS Topology |
Line-Interactive (AVR) |
| Energy Saving |
Yes - GreenPower UPS Bypass Technology |
| Active PFC Compatible |
Yes |
| Voltage |
90Vac - 140Vac |
| Frequency |
57Hz - 63Hz |
| Plug Type |
NEMA 5-15P |
| Plug Style |
Right angle, 45 degree offset to the right |
| Cord Length |
5' / 1.5 m |
| Output |
VA: 1500 Watts: 900 |
| Automatic Voltage Regulation |
88VAC-102VAC |
| On Battery Voltage |
120Vac +/- 5% |
| On Battery Frequency |
60Hz +/- 1% |
| On Battery Waveform |
Sine Wave |
| Overload Protection |
Internal circuitry limiting / circuit breaker |
| Outlets: Total |
10 |
| Outlets: Battery & Surge Protected |
5 |
| Outlets: Surge-Only Protected |
5 |
| USB Charge Port |
Yes - Two (2) USB 5V/1A charging ports |
| Transfer Time |
4ms |
| Runtime at Half Load (min) |
11 |
| Runtime at Full Load (min) |
2 |
| Battery Type |
Sealed lead acid |
| Battery Size |
12V/8.5AH |
| User Replaceable |
Yes |
| Hot Swappable |
No |
| Typical Recharge Time |
8 Hours |
| Replacement Battery |
BB Battery - HR1234W |
| Battery Quantity |
2 |
| Surge Suppression |
1,030 Joules |
| Phone / Ethernet RJ11 / RJ45 |
1-In, 1-Out (Combo) |
| Coax Protection RG6 |
1-In, 1-Out |
| Multifunction LCD Diagnostic Display |
Toggle Status Display includes: Current/Load Level, Runtime, Battery Level, AVR In Use, Battery In Use, Input Voltage, Output Voltage, Output Frequency, Overload, Wiring Fault, Silent Mode |
| HID Compliant USB Port |
Yes |
| Serial Port |
Yes |
| Management Cable |
USB Cable |
| LED Indicators |
Power on, wiring fault |
| Audible Alarms |
On battery, low battery, overload, fault |
| Software |
PowerPanel Personal Edition |
| Emergency Power Off (EPO) Port |
No |
| Form Factor |
Tower |
| Operating Temperature |
32 Deg.F to 104 Deg.F / 0 Deg.C to 40 Deg.C |
| Operating Humidity |
0% - 90% non-condensing |
| Certifications |
UL1778, cUL 107.3, FCC DOC Class B |
| ROHS |
ROHS Compliant |
| Dimensions (W x H x D) |
3.9" x 10.4" x 14.2" / 9.90 x 26.4 x 36.0 cm |
| Weight |
24.7 lbs / 11.2 kg |
