| Print technology |
Direct-to-card dye-sublimation/resin thermal transfer |
| Print capabilities |
One- or two-sided, edge-to-edge printing
Full-color and monochrome printing capability
Alphanumeric text, logos and digitized signatures; 1D/2D bar code images
Printer pooling/sharing (available soon) |
| Print resolution |
300 dots per inch, 256 shades per color panel |
| Print quality |
Ability to conform to sRGB standard
Flexible color management options |
| Print speed |
Full-color: up to 200 cards per hour, one-sided (YMCKT); up to 155 cards per hour, two-sided (YMCKT-K)
Monochrome: up to 830 cards per hour, one-sided (black HQ) |
| Printer memory |
128 MB standard |
| Card capacity |
Automatic feed: 100-card input for 0.030 in.
(0.76 mm) cards; 25-card output standard
Manual feed: 1-card input; 5-card output for 0.030 in.
Front exception card slot
Separate reject location and holding tray (SD360)
Input hopper empty detection (SD360) |
| Printer display |
Printer status messages
Multiple backlight settings
International languages available: English, Spanish, German, Italian and Japanese |
| Printer driver |
Adjustable color controls with image preview
Pre-set area to block printing on magnetic stripe, with escapes for custom areas
Utilizes Windows XPS-based technology for high-fidelity printing
Secure disabling of card remake
Software Development Kit (SDK) for Windows operating system printer driver
User interface languages available: English, Spanish, German, Italian, Japanese, Traditional Chinese, Portuguese, Korean and Arabic |
| User-friendly operation |
Printer messages display on LCD panel
Graphical display on Windows 7 and Windows Vista operating systems
Easy, fast installation
Card remake standard with cancel option
Operator-replaceable printhead
Front panel soft power button |
| Supplies Technology |
Automatic identification and validation for ribbons
Adjustable low ribbon and cleaning cycle alerts
Ribbon saver |
| Magnetic stripe encoding |
ISO 7811 three-track option (high- and low-coercivity)
JIS Type II single-track option
Support for standard and custom data formats |
| Smart card personalization |
Field upgradeable
Contact/contactless all-in-one reader
iCLASS by HID, read/write encoder
Third-party OEM smart card option-ready |
| End-user upgradeable options |
Extended 200-card input hopper |
| Print ribbon kits - color |
Full-color with resin black and topcoat panel on front, resin black on back, YMCKT-K, 375 images (SD360)
Resin black with inline double topcoat, KTT, 750 images |
| Print ribbon kits - monochrome |
Resin black HQ (high quality), 500 images
Resin black HQ (high quality), dark blue, white, red, green, silver, gold, metallic silver, metallic gold, 1500 images |
| Electronic requirements |
100/120V, 50/60 Hz
220/240V, 50/60 Hz |
| Plastic cards accepted |
ISO ID-1/CR-80 size cards;
3.370 in. x 2.125 in. (85.6 mm x 53.98 mm)
PVC with glossy laminate surface
Select key fob cards (ISO ID-1/CR-80 size cards)
Datacard StickiCard adhesive-backed plastic cards |
| Card thickness accepted |
0.010 in. to 0.037 in. (0.254 mm to 0.939 mm) |
| Operating environment |
60deg.F to 95deg.F (15deg.C to 35deg.C)
20% to 80% non-condensing humidity |
| Storage environment |
5deg.F to 140deg.F (-15deg.C to 60deg.C)
10% to 90%, non-condensing humidity |
| Connectivity |
Bidirectional USB 2.0 high speed
Ethernet 10 Base-T/100-Base-TX (with activity light) |
| Operating system support |
Windows 7 / Windows Vista (32 and 64 bit)
Windows Server 2008 (64 bit)
Windows XP SP3 / Windows Server 2003 R2 (32 bit)
Microsoft Windows Hardware Quality Labs (WHQL) certified |
| Dimensions (LxWxH) |
21.2x6.9x8.8" (53.9x17.5x22.4 cm) |
| Weight |
12 lbs (5.4 kg) |
