| Brightness |
2500 ANSI Lumens (Max) |
| Contrast Ratio |
2200:1 Typical (Full On/Full Off) |
| Resolution |
SVGA native resolution (800x600) |
| Uniformity |
90% Typical (Japan Standard - JBMA) |
| Projection Lens |
F-Stop: F/ 2.41-2.55 Focal length, f=21.8-24mm Zoom Lens: Manual 1.1x Throw ratio: 1.95 (wide) - 2.15 (tele) |
| Image Size |
22.9" - 303" (diagonal) |
| Projection Distance |
3.28 ft - 39.37 ft (1m - 12m) |
| Lamp Life Cycle |
Up to 3000-hour Typical Up to 4000-hour Eco-Mode |
| Lamp Type |
Philips 185W user-replaceable |
| Audio |
Multimedia Audio:2W Speaker |
| Connectivity: Power |
One AC power socket (3-pins - C14 inlet) |
| Connectivity: VGA input |
Two 15-pins D-sub connectors (Blue), VGA-A & VGA-B, for analog RGB/Component input signals. |
| Connectivity: VGA output |
One 15-pins D-sub connector (Black)for VGA-A loop through. |
| Connectivity: S-Video input |
One standard 4-pins min-DIN SVideo connector for Y/C signal. |
| Connectivity: Composite video input |
One Yellow RCA jack for CVBS signal. |
| Connectivity: Analog Audio input |
One 3.5mm stereo mini phone jack (Green). |
| Connectivity: Fix audio output |
One 3.5mm stereo mini phone jack (Blue). |
| Connectivity: USB port |
One USB slave for remote support. |
| Composite Video / S-Video |
NTSC (M, 3.58, 4.43), PAL (B, D, G, H, I, M, N, 4.43), SECAM (B, D, G, K, K1, L, 4.25/4.4) |
| Component Video via VGA |
1080i/p, 720p, 576i/p, 480i/p |
| Keystone Correction: Vertical |
+40deg. / -35deg. |
| Power |
Universal 90-264V AC 50Hz-60Hz |
| Power Consumption Operational |
Normal mode: 234W Eco mode: 209W Power saving mode: less than 14W (Fan speed at minimum) Standby mode: less than 1W |
| Operating temperature |
5deg.C - 35deg.C (41deg.F - 95deg.F) |
| Operating Humidity |
80% (maximum) |
| Storage temperature |
0deg.C - 60deg.C (32deg.F - 140deg.F) |
| Storage Humidity |
90% (maximum) |
| Dimensions (W x H x D) |
11.26 x 3.54 x 7.56 inches (286 x 89.91 x 192 mm) |
| Weight |
5.3 lbs(2.40 kg) |
