D-Link DGS-108 8-Port Gigabit Ethernet Switch

D-Link
SKU: DLDGS108 MFR: DGS-108
D-Link DGS-108: Picture 1 thumbnail D-Link DGS-108: Picture 2 thumbnail

Our Price

$52.14
Buy more and save
Quantity Discount
QuantityAmount

The quantity discount will be reflected in your shopping cart

About D-Link DGS-108

The D-Link DGS-108 8-Port Gigabit Ethernet Switch provides eight speedy Gigabit Ethernet auto-sensing ports for connecting multiple computer devices to your network. Once you've connected the switch to your network via one Gigabit Ethernet port, you will have seven other ports for connecting printers, scanners, storage, backup devices and more. Support for Quality of Service (QoS) means the switch will prioritize network traffic that is sensitive to lags, such as video streaming or VoIP calls. The switch is unmanaged and plug-and-play, so you need not install software first to use it or configure settings for it later.

D-Link DGS-108 Features

  • Built-in D-Link Green Technology
  • Rugged metal housing
  • Inexpensive Gigabit solution for small and medium business
  • A total of eight Gigabit Ethernet ports
  • 16Gbps switching fabric
  • Auto MDI/MDIX crossover for all ports
  • Secure store-and-forward switching scheme
  • Full/half-duplex for Ethernet/Fast Ethernet speeds
  • IEEE 802.3x Flow Control
  • Supports Jumbo Frames
  • With support for IEEE 802.1p Quality of Service, the switch organizes and prioritizes time-sensitive and important data for efficient delivery, allowing for smooth media streaming and VoIP calling
  • The D-Link Cable Diagnostics Function enables users to be instantly aware of cable conditions through the LED display on the front-panel
  • The switch can also save energy by detecting the cable length and using only as much power as necessary
  • As a switch supporting IEEE 802.3az Energy-Efficient Ethernet (EEE), the switch can detect when a connected computer is shut down or when there is no Ethernet traffic, at which time the switch will automatically power down the idle port, saving a substantial amount of power
  • RoHS compliant
  • Plug-and-play installation

D-Link DGS-108 Specifications

Standards
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
ANSI/IEEE 802.3 NWay auto-negotiation
IEEE 802.3x flow control
IEEE 802.3az Energy Efficient Ethernet (EEE)
Protocols
CSMA/CD
Ports
8x Gigabit Ethernet 10/100/1000Mbps LAN Ports
Switching fabric
16 Gbps
Data Transfer Rates
Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
Gigabit Ethernet: 2000 Mbps (full duplex)
Packet Filtering/Forwarding Rates
Ethernet: 14,880 pps per port
Fast Ethernet: 148,800 pps per port
Gigabit Ethernet: 1,488,000 pps per port
RAM Buffer
128 KB
Cables
10BASE-T:
UTP CAT 3, 4, 5/5e (100 m max.)
EIA/TIA-586 100-ohm STP (100 m max.)
100BASE-TX, 1000BASE-T:
UTP CAT 5/5e (100 m max.)
EIA/TIA-568 100-ohm STP (100 m max.)
Jumbo Frames
9,000 Bytes
Switching Method
Store-and-forward
LED Indicators
Per port: Link/Activity/Speed
Per device: Power
Quality of Service (QoS)
Supports 802.1p QoS
4 Queues, Strict Mode
D-Link Green
Power saving by cable length detection
Compliant
RoHS
Power
External 5 V/1 A Level "V" Power Adapter
Power Consumption (DC input)
Standby: 0.55 watts
Maximum 2.8 watts
System Requirements
For network connection: Ethernet-enabled router or modem
For sharing network connection: Ethernet-enabled devices
Heat Dissipation
Power On (Standby) AC input: 3.41 BTU/h
Maximum DC input: 9.548 BTU/h
MTBF
2,053,751 hours
Temperature
Operating: 0 to 50 deg.C
Storage: -10 to 70 deg.C
Humidity
Operating: 10% to 90% RH non-condensing
Storage: 5% to 90% RH non-condensing
Certifications
FCC Class B
ICES-003 Class B
CE Class B
C-Tick Class B
VCCI Class B
cUL
CB
Dimensions (WxDxH)
162x102x28mm / 6.37x4.01x1.10"
