| Connectivity |
2 x 10/100/1000 Mbps Ethernet ports |
| Capacity |
8 drive bays 3.5" SATA 1 / SATA II drives |
| BeyondRAID |
Thin Provisioning Instant Expansion Mixed Drive Size Utilization Automatic Protection Levels Dual Disk Redundancy Virtual Hot Spare Data Aware Drive Re-ordering |
| Ethernet Features |
Connection failover Jumbo Frames (up to 9000 Kb MTU) |
| Network Protocols |
Common Internet File System (CIFS)/ Server Message Block (SMB) Apple Filing Protocol (AFP) |
| Operating System Support |
Windows 7 Windows Vista (Service Pack 1) Windows XP (Service Pack 3) Windows 2008 Server Windows 2003 Server Mac OS X 10.5.6 or greater (Intel Only) Mac OS X Server 10.5.6 or greater (Intel Only) Linux (support is currently in Beta) |
| Management |
Drive bay indicator lights, capacity gauge, status lights Drobo Dashboard version 2.0 or later |
| Acoustics |
Normal operation: 30.4 dB |
| Certifications |
Environmental: RoHS; WEEE; REACH Regulatory: FCC Part 15 Class B; Canada ICES-003 Class B; CE Mark; CISPR22:19973rd Edition Class B; MIC Mark; VCCI Approval to V.3; BSMI Approval to CNS13438; ACA Approval to AS/NZS 3548 Safety: UL; cUL; TUV; CB |
| Dimensions (W x H x D) |
12.17" x 5.46" x 14.10" / 30.91 x 13.86 x 35.81 cm |
| Weight |
16 lbs 3 oz / 7.34 kg |
