| Panel Size |
23" / 58 cm (584 mm diagonal) |
| Active Display Size (H x V) |
509.8 x 286.7 mm |
| Panel Type |
IPS (with overdrive circuit) |
| Viewing Angles (H, V) |
178 Deg., 178 Deg. (at contrast ratio of 10:1) |
| Brightness |
250 cd/m2 |
| Contrast |
1000:1 (1500:1 with Contrast Enhancer) |
| Response Time (Typical) |
Gray-to-gray: 6 ms, black-white-black: 16 ms |
| Native Resolution |
1920 x 1080 (16: 9 aspect ratio) |
| Pixel Pitch |
0.265 x 0.265 mm |
| Display Colors |
16.77 million from a palette of 1.06 billion |
| Look-Up Table |
10 bits per color |
| Dot Clock |
Analog: 148.5 MHz, Digital: 148.5 MHz |
| Analog Scanning Frequency (H, V) |
PC: 31 - 81 kHz, 55 - 76 Hz |
| Digital Scanning Frequency (H, V) |
PC: HDMI: 31 - 68 kHz, 49 - 61 Hz (VGA Text: 69 - 71 Hz) DVI: 31 - 68 kHz, 59 - 61 Hz (VGA Text: 69 - 71 Hz) |
| Video Input Terminals |
PC: D-Sub mini 15 pin, DVI-D 24 pin (with HDCP) PC / AV: HDMI x 2 (AV: 1080p / 720p / 480p) |
| Audio Input Terminals |
PC: 3.5 mm stereo jack x 1 PC / AV: HDMI x 2 |
| Audio Output Terminals |
PC / AV: 3.5 mm headphone jack |
| Speakers |
0.5 W + 0.5 W (stereo) |
| Plug & Play |
VESA DDC 2B |
| Power Requirements |
100 - 120 V / 200 - 240 V, 50 / 60 Hz |
| Power Consumption |
20 W (typical) 34 W (maximum) |
| Power Save Mode |
Less than 1.0 W |
| Tilt |
20 Deg. Up, 5 Deg. Down |
| Preset Modes |
PC / AV: User1, User2, sRGB, Paper, Game, Cinema, Auto Fine Contrast |
| EcoView Settings |
Auto EcoView, EcoView Index |
| Screen Adjustment |
PC: Clock, Phase, Position, Resolution, Screen (Auto), Range (Auto) |
| Screen Size |
PC: Normal, Enlarge, Full Screen AV: Auto, Normal, Letterbox, Enlarge, Full Screen |
| Color Adjustment |
PC/ AV: Brightness, Black Level, Contrast, Gamma, Temperature, Saturation, Hue, Gain, Contrast Enhancer, Smart Resolution (Skin Tone Enhancer, Text Enhancer, Video Area Enhancer), Overdrive, Reset |
| Power Management |
Power Save (VESA DPM and DVI DMPM), Off Timer |
| Sound |
Volume, Mute, Sound Level, Power Save, Source (HDMI) |
| Certifications and Standards |
TCO Displays 5.2, EPEAT Silver (US),TUV/Ergonomics (including ISO 13406-2), TUV/GS, TUV/NRTL, c-Tick, CE, CB, cTUVus, FCC-B, Canadian ICES-003-B, TUV/S, VCCI-B, EPA Energy Star, RoHS, WEEE, CCC |
| Dimensions (W x H x D) |
With Stand: 549 x 403 x 212 mm / 21.6 x 15.9 x 8.3" Without Stand: 549 x 393 x 58 mm / 21.6 x 15.5 x 2.3" |
| Weight |
With Stand: 6.2 kg / 13.7 lbs Without Stand: 5.4 kg / 11.9 lbs |
