| Panel Size |
22" / 56 cm (558 mm diagonal) |
| Active Display Size (H x V) |
473.8 x 296.1 mm |
| Panel Type |
VA (with overdrive circuit) |
| Viewing Angles (H, V) |
178 Deg., 178 Deg. (at contrast ratio of 10:1) |
| Brightness |
280 cd/m2 |
| Contrast |
1000:1 |
| Response Time (Typical) |
Gray-to-gray: 6 ms, black-white-black: 12 ms |
| Native Resolution |
1920 x 1200 (16:10) |
| Pixel Pitch |
0.247 x 0.247 mm |
| Display Colors |
DVI: 16.77 million from a palette of 278 trillion DisplayPort: 1.07 billion from a palette of 278 trillion |
| Wide Gamut Coverage |
Adobe RGB: 95%, 92% vs. NTSC |
| Look-Up Table |
16 bits per color |
| Dot Clock |
Analog: 170 MHz, Digital: 164.5 MHz |
| Analog Scanning Frequency (H, V) |
31 - 76 kHz, 49 - 86 Hz |
| Digital Scanning Frequency (H, V) |
31 - 76 kHz, 59 - 61 Hz (VGA Text: 69 - 71 Hz) |
| Video Input Terminals |
DVI-I 29 pin x 2 (with HDCP), DisplayPort (with HDCP) |
| USB Ports / Standard |
1 upstream, 2 downstream / USB 2.0 |
| Plug & Play |
VESA DDC 2B |
| Power Requirements |
AC 100 - 120 V / 200 - 240 V, 50 / 60 Hz |
| Power Consumption |
45 W (typical) 90 W (maximum) |
| Power Save Mode |
Less than 0.9 W |
| Height Adjustment Range |
174 mm |
| Tilt / Swivel / Pivot |
30 Deg. Up, 0 Deg. Down / 172 Deg. Right, 172 Deg. Left / 90 Deg. |
| Preset Modes |
Color Mode (Text, Picture, Movie, sRGB, User1, User2, User3), Auto Fine Contrast |
| EcoView Settings |
Auto EcoView, EcoView Index |
| Screen Adjustment |
Clock, Phase, Position, Range (Auto), Screen Size (full screen, enlarge, normal) |
| Color Adjustment |
Brightness, Contrast, Independent 6-Color Control, Gamma, Temperature, Saturation, Hue, Gain, Contrast and Outline Enhancer, Reset |
| Power Management |
Power Save (VESA DPM, DisplayPort Rev. 1.1a and DVI DMPM), Eco Timer |
| Certifications and Standards |
CUDO certified mark, TCO'03, TUV/Ergonomics (including ISO 9241-307 [Pixel fault class I]), TUV/GS, c-Tick, CE, CB, cTUVus, FCC-B, Canadian ICES-003-B, TUV/S, VCCI-B, RoHS, WEEE, CCC, GOST-R |
| Dimensions (W x H x D) |
With Stand: 20.1 x 13.7 - 20.5 x 9.5 - 10.1" (51.1 x 34.8 - 52.2 x 24.1 - 25.6cm) Without Stand: 20.1 x 13.1 x 3.4" (51.1 x 33.3 x 8.5cm) |
| Weight |
With Stand: 23.6 lb (10.7kg) Without Stand: 14.6 lb (6.6kg) |
