| Image Sensor Type |
Color CCD (Color Charge Coupled Device x 2) |
| Light Source |
White cold cathode discharge lamps |
| Optical Resolution |
600 dpi |
| Output Resolution: Color (24 bit) |
50 to 600 dpi (adjustable by 1 dpi increments), 1200 dpi |
| Output Resolution: Grayscale (8 bit) |
50 to 600 dpi (adjustable by 1 dpi increments), 1200 dpi |
| Output Resolution: Monochrome |
50 to 600 dpi (adjustable by 1 dpi increments), 1200 dpi |
| Output Format |
Color: 24-bit, 8-bit,4-bit, Grayscale: 8-bit, 4-bit, Monochrome: 1-bit |
| Internal Video Processing |
1024 levels (10-bit) |
| Output (Letter/A4 size): Color 200 dpi |
Simplex: 40 ppm Duplex: 80 ipm |
| Output (Letter/A4 size): Color 300 dpi |
Simplex: 30 ppm Duplex: 60 ipm |
| Output (Letter/A4): Grayscale 200 dpi |
Simplex: 40 ppm Duplex: 80 ipm |
| Output (Letter/A4): Grayscale 300 dpi |
Simplex: 30 ppm Duplex: 60 ipm |
| ADF capacity |
50 Sheets (letter/A4, 20 lb.) |
| Document size |
ADF minimum: 2 in. x 3 in. (52mm x 74mm) ADF maximum: 8.5 in. x 14 in. (Legal) Long Document: 8.27 in. x 120 in. (10 feet) |
| ADF Feeding Paper Weight (Thickness) |
Letter: 11 to 56.2 lb. (41 to 210g/m2) A8 sheets: 34 to 56.2 lb. (127 to 210g/m2) Card: Portrait and Landscape feeding |
| Interface |
USB 2.0 (B type connector) |
| Power requirements |
100-240 VAC, 50/60 Hz |
| Power consumption |
38 W or less (Sleep: 5.36W or less) |
| Environmental Compatibility |
ENERGY STAR and RoHS |
| Operating Temperature |
42deg. to 95deg.F (5deg. to 35deg.C) |
| Relative humidity |
20%-80% (non-condensing) |
| Dimensions (W x D x H) |
11.8 x 6.4 x 6.2 in. (301 x 160 x 158 mm) |
| Weight |
9.24 lb. (4.2 kg) or less |
