Gefen 8x8 Matrix for HDMI, Black

Please note! This item will be Drop-shipped to you directly from the Manufacturer/Distributor.
Estimated Delivery time is from 3 to 5 Days.
Why Adorama?
Easy Returns, Fast Shipping, Trusted for over 35 years.

Need help? Call 800-223-2500 212-741-0052

Our Price

Free Shipping

Add to Wishlist

About this item

The Gefen 8x8 Matrix for HDMI routes eight high-definition sources to any eight HDTV displays. Resolutions up to 1080p Full HD and 1920 x 1200 plus 3DTV are supported, along with multichannel digital audio formats such as Dolby True HD and DTS-HD Master Audio.

The 8x8 Matrix eliminates the need to disconnect and reconnect high-definition. It works with any high-definition source that needs to be connected to any display using HDMI. Each source can be routed to any display using the front-panel push buttons, IR remote control, RS-232 interface, or over IP using the built-in web interface.

What's Included With This Item

  • Gefen 8x8 Matrix for HDMI
  • 24V DC Power Supply (EXT-PS24U4A848CP)
  • AC Power Cord (CAB-POWERCORD-US)
  • IR Remote Control (RMT-848IR)
  • Quick-Start Guide (QSG-GTB-HDFST-848)
  • Gefen 2 Years Warranty

Key Features

  • Route any eight Hi-Def sources to any eight HDTV displays
  • Supports resolutions up to1080p Full HD and 12-bit Deep Color
  • Supports 3DTV pass-through
  • Supports LPCM 7.1 audio, Dolby Digital Plus, Dolby TrueHD and DTS-HD Master Audio
  • Advanced EDID Management for rapid integration of sources and displays
  • Gefen FST speeds up the HDCP authentication process
  • Fast and Slow FST Modes
  • Front Panel Push-Button Switching
  • Supports the use of DVI sources and displays with HDMI-to-DVI cables or adapters
  • IP Control via Web Graphical User Interface and Telnet
  • RS-232 serial control for automation
  • IR Remote Control (handheld remote included)
  • Field-upgradable firmware via built in Web Graphical User Interface
  • 24V Power Supply
  • Wall-mountable
  • Uses Gefen Mono-LOK HDMI connectors for secure cable connections

Technical Specs

Maximum Pixel Clock 225 MHz
Video Input Connectors 8 x HDMI Type A 19-pin female, locking
Video Output Connectors 8 x HDMI Type A 19-pin female, locking
IP Connector RJ-45, female, Shielded
USB Port Mini-B, female
RS-232 Port DB-9, female
IR Extender Port 3.5mm mini-stereo jack
Power Supply 24V DC
Operating Temperature 0 - 40 deg.C
Dimensions (WxHxD) 9.3x16.8x1.8" / 23.62x42.67x4.57cm
