The Griffin Technology StudioConnect allows you to record audio and MIDI data to any Core Audio compatible app on your iPad, iPad 2, or iPad 3. It features a 1/4" mono instrument input for connecting a guitar, bass, or any other instrument level device. A stereo 1/8" connector rounds out the audio input capabilities on the StudioConnect.
The unit also acts as a MIDI interface thanks to its 5-pin DIN MIDI input and output connectors. You can monitor your audio playback from either the stereo RCA outputs or the front-panel 1/8" stereo headphone jack. The StudioConnect has a 30-pin iOS cable for connecting to your iPad and acts as a 10-watt charging dock while in use.
|Audio Input||1x 1/4" (6.3 mm) mono
1x 1/8" (3.5 mm) stereo
|Audio Output||2x line level RCA
1x 1/8" (3.5 mm) headphone jack with volume control
|Compatibility||iPad, iPad 2, or iPad 3|
|MIDI||1x 5-pin DIN input 1x 5-pin DIN output|
|Connector||1x 30-pin connector|
|Charging||10 watts (5 volts DC at 2.1 amps)|
