The Griffin Technology StudioConnect with Lightning Connector allows you to record audio and MIDI data to any Core Audio compatible app on your iPad 4th generation or iPad mini. It features a 1/4" mono instrument input for connecting a guitar, bass, or any other instrument level device. A stereo 1/8" connector rounds out the audio input capabilities on the StudioConnect.
The unit also acts as a MIDI interface thanks to its 5-pin DIN MIDI input and output connectors. You can monitor your audio playback from either the stereo RCA outputs or the front-panel 1/8" stereo headphone jack. The StudioConnect has a Lightning iOS cable for connecting to your iPad and acts as a 10-watt charging dock while in use.
|Audio Input||1/4" Mono
|Audio Output||Line-level stereo R and L RCA
Front-panel 3.5mm Stereo Headphone Jack with Volume Control
|Compatibility||iPad 4th Generation, iPad mini/mini 2, iPad Air|
|MIDI||1x 5-pin DIN input 1x 5-pin DIN output|
|Connector||1x 30-pin connector|
|Charging||10Watts (5 volts DC at 2.1 amps)|
