| LCD Panel |
0.79" P-Si TFT x 3 with Micro Lens |
| Resolution |
SXGA+ (1400 x 1050) |
| Brightness |
Normal Mode 4000 ANSI Lumens Eco Mode 3200 ANSI Lumens |
| Contrast Ratio |
1000:1 (Iris On) |
| Lens |
1.7-2.1 1.5 Zoom |
| Focus/Zoom Adjusting |
Manual Zoom, Manual Focus |
| Lamp |
275W |
| Lamp Life |
2000 (normal) / 4000 (eco) |
| Diagonal display size |
60" @ 1.8m, 30-350" standard lens |
| Number of Color |
10bit / Color |
| Lens shift (Optical Keystone) |
1:1 to 9:1 upward shift(Manual lens shift) Horizontal(4:6-6:4) at vertical lens shift 1:1 |
| Computer compatibility |
IBM Compatible VGA, SVGA, XGA, SXGA+, UXGA compressed, MAC 16" |
| Video compatibility |
NTSC / PAL / SECAM / PAL-M,N / NTSC4.43 SDTV: 525i(480i), 525p(480p), 625i(576i) HDTV: 750p(720p@60Hz), 1125i(1080i@50 / 60Hz), 1125p(1080p@50 / 60Hz) |
| Plug & Play |
DDC2B |
| Computer Input |
1 x 15-pin Mini D-sub 1 x HDMI 1 x BNC |
| Computer output |
1 x 15-pin Mini D-sub |
| Video Input |
1 x RCA?Jack 1 x S-Video Jack 3 x RCA Jack for Component |
| Audio Input |
2 x Stereo Mini Jack 2 x Pair RCA (L / R) (Selectable on OSD) |
| Audio Output |
1 x Stereo Mini Jack |
| Control and Mouse |
1 x 9-pin D-sub for RS232 control 1 x USB type B for mouse control |
| Wired network |
1 x RJ-45 |
| Power Supply |
100-120V / 220-240V auto switching |
| Power Consumption |
460W |
| Certification |
UL60950 / C-UL, FCC Part 15 Class A, CE, AS / NZS CISPR22 Class A |
| Noise level |
35dB (Normal Mode) / 29dB (Eco Mode) |
| Air filter |
Hybrid |
| Dimensions (W x H x D) |
16.4 x 5.47 x 12.5 inches / 418 x 139 x 319mm (excluding feet and extrusions) |
| Weight |
15.7 lbs (7.12kg) |
