| Compatibility |
H System Components |
| Sensor size |
40.0 Megapixels (7304 x 5478 pixels) |
| Sensor dimensions |
32.9 x 43.8 mm |
| Image size |
RAW 3FR capture 50 MB on average. TIFF 8 bit: 120 MB |
| File format |
Lossless compressed Hasselblad RAW 3FR |
| Lenses |
Hasselblad H system lens line with integral central lens shutter |
| Shutter speed range |
256 seconds to 1/800 second |
| ISO speed range |
ISO 100, 200, 400, 800 and 1600 |
| Color definition |
16 bit |
| Color management |
Hasselblad Natural Color Solution |
| Focusing |
Autofocus metering with passive central cross-type sensor. Ultra focus digital feedback. Instant manual focus override. Metering range EV 1 to 19 at ISO 100 |
| Display |
3" TFT type, 24-bit color, 230,400 pixels |
| Histogram |
Yes |
| IR filter |
Mounted on CCD sensor |
| Exposure metering |
Metering options: Spot, Centre Weighted and CentreSpot Metering range Spot: EV2 to 21 Centre Weighted: EV1 to 21 Centre Spot: EV1 to 21 |
| Power supply |
Rechargeable Li-ion battery (7.2 VDC / 1850 mAh) |
| Storage options |
CF card type U-DMA/Tethered to Mac or PC |
| Storage capacity |
4 GB CF card holds 75 images on average |
| Capture rate |
1.1 seconds per capture. 50 captures per minute |
| Software |
Phocus for Mac and Windows |
| Platform support |
Macintosh: OSX Windows: XP (32 and 64 bit), Vista (32 and 64 bit), Windows 7 (32 and 64 bit) |
| Host connection type |
FireWire 800 (IEEE 1394b) |
| Operating temperature |
0 - 45 deg.C/32 - 113 deg.F |
| Dimensions (W x H x D) |
With HC80 mm lens: 6.02 x 5.16 x 8.39" (153 x 131 x 213mm) |
| Weight |
5.05 lb (2.29 kg) (Complete camera w. HC80 mm lens, Li-Ion battery and CF card) |
