| Product Type |
Digital AF/AE SLR |
| Recording Medium |
CF Card Type I and II, SD/SDHC Memory Card (1 slot each), and/or External media (USB v.2.0 hard drive, via optional Canon WFT-E2A transmitter), compatible with UDMA-compliant CF cards, and SDHC SD cards |
| Image Format |
1.42 x 0.94 in./36.0 x 24.0mm (full-frame sensor) |
| Compatible Lenses |
Canon EF, TS-E, and MP-E lenses (except EF-S lenses) |
| Lens Mount |
Canon EF mount |
| Lens Focal Length Conversion Factor |
1.0x |
| Image Sensor Type |
Full-frame, high-sensitivity, high-resolution, single-plate, CMOS sensor |
| Pixels |
Approx. 21.10 megapixels |
| Total Pixels |
Approx. 21.90 megapixels |
| Aspect Ratio |
3:2 (Horizontal : Vertical) |
| Color Filter System |
RGB primary color filters |
| Low-pass Filter |
Fixed position in front of the CMOS sensor |
| Recording Format |
DCF 2.0 (Exif 2.21): JPEG, RAW and RAW+JPEG simultaneous recording possible. Multiple options for recording images on two memory cards, and onto compatible external USB hard drives (via optional Wireless File Transmitter WFT-E2A) |
| Image Format |
JPEG, JPEG+RAW, RAW (Canon CR2) |
| File Size |
JPEG/Large: Approx. (TBA) MB (5,616 x 3,744)
JPEG/Medium 1: Approx. (TBA) MB (4,992 x 3,328)
JPEG/Medium 2: Approx. (TBA) MB (4,080 x 2,720)
JPEG/Small: Approx. (TBA) MB (2,784 x 1,856)
RAW: Approx. (TBA) MB (5,616 x 3,744)
sRAW: Approx. (TBA) MB (2,784 x 1,856) |
| Recording System Folders |
Can be manually created by user, and freely selected for subsequent images. |
| File Numbering |
Continuous numbering
Auto reset
Manual reset (the image numbering is reset to 0001, a new folder is created automatically) |
| Color Space |
Selectable between sRGB and Adobe RGB |
| Interfaces |
USB 2.0 Hi-Speed, mini-B port. NTSC/PAL for video output |
| Settings |
Auto, Daylight, Shade, Cloudy, Tungsten Light, White Fluorescent Light, Flash, five Custom WB settings (1-5), user-set Color Temperature (2,500~10,000K), five Personal White Balance PC-1 to PC-5 |
| Auto White Balance |
Auto white balance, taken from imaging sensor |
| Personal White Balance |
White balance bracketing: Three consecutive images, Up to +/- 3 levels in 1-step increments
White balance shift: blue/amber bias and/or magenta/green bias +/- 9 levels; manually set by user |
| Viewfinder Type |
Eye-level SLR with fixed pentaprism |
| Coverage |
Approx. 100% horizontally and vertically |
| Magnification |
0.76x (-1 dpt with 50mm lens at infinity) |
| Eyepoint |
Approx. 20mm |
| Dioptric Adjustment Correction |
-3.0 to +1.0 diopter |
| Mirror |
Quick-return half mirror (Transmission: reflection ratio of 37:63) |
| Viewfinder Information |
AF (AF points, focus confirmation light, point selection mode, registration), Exposure (metering mode, spot metering area, shutter speed, aperture, manual exposure, AE lock, ISO speed, exposure level, exposure warning), Flash (flash ready, high-speed sync, FE lock, flash exposure level), Image (JPEG recording, RAW recording, shots remaining, maximum burst, white balance correction, memory card information), Battery check |
| Depth-of-Field Preview |
Enabled with depth-of-field preview button; possible in Live View Function |
| Eyepiece Shutter |
Built-in |
| Auto Focus Type |
TTL-AREA-SIR AF-dedicated CMOS sensor |
| AF Point Selection |
45-point (19 high-precision cross-type AF points plus 26 Assist AF points) |
| AF Working Range |
EV -1 ~18 (ISO 100 at 73°F/23°C) |
| Focusing Modes |
Autofocus (One-Shot AF, Predictive AI Servo AF), Manual Focus (MF) |
| AF Point Selection |
Automatic selection; Manual selection: 19 AF points, or only inner 9 AF points (C.Fn III-9-1), or outer 9 AF points (C.Fn III-9-2) |
| Selected AF Point Display |
Superimposed in viewfinder and on LCD panel |
| AF-assist Beam |
None. Emitted by EX-series Speedlite or optional ST-E2 Speedlite Transmitter |
| Metering Modes |
63-zone TTL full aperture metering
Evaluative metering (linked to all AF points)
Partial metering (approx. 8.5% of viewfinder)
Spot metering (approx. 2.4% of viewfinder)
Center spot metering
AF point-linked spot metering (C.Fn. I-7-1)
Multi-spot metering (max. 8 spot metering entries)
Center-weighted average metering |
| Metering Range |
EV 0-20 (ISO 100 at 73°F/23°C with EF 50mm f/1.4 USM lens, ISO 100) |
| Exposure Control Method |
Program AE (shiftable), Shutter speed-priority AE, Aperture-priority AE, E-TTL II program AE (Evaluative flash metering, Averaged flash metering), Manual, Bulb |
| ISO Speed Range |
Equivalent to ISO 100-1600 (in 1/3-stop or whole stop increments), ISO speed can be expanded to ISO 50 and 3200 (via C.Fn I-3) |
| Exposure Compensation |
Exposure Compensation (user-set): up to +/-3 stops in 1/3- or 1/2-half increments
Auto Bracketing (AEB): 3 shots, up to +/- 3 stops, in 1/3 or 1/2 stop increments, in all exposure modes. Sequence can be changed via C.Fn I-5 |
| AE Lock |
Auto: Applied in One-Shot AF mode with evaluative metering when focus is achieved
Manual (user-set): By AE lock button in all metering modes |
| Shutter Type |
Vertical-travel, mechanical, focal-plane shutter with all speeds electronically controlled |
| Shutter Speeds |
1/8000 to 30 sec. (1/3-, 1/2- or 1-stop increments), X-sync at 1/250 sec. (with EOS dedicated external Speedlites; 1/250 maximum with other shoe-mount flashes, and 1/60th-1/250th with studio strobes) |
| Shutter Release |
Soft-touch electromagnetic release |
| Self-timer |
10 sec. delay, 2 sec. delay |
| Remote Control |
Canon N3 type terminal |
| EOS External Flash/Dedicated Speedlites |
E-TTL II autoflash with all EX Series Speedlites |
| PC Terminal |
Provided; accepts third-party flash units with sync line voltages up to 250V maximum |
| Drive Modes |
Single, silent, high-speed continuous (approx. 5 fps), low-speed continuous (approx. 3 fps), 10- or 2-sec. self-timer |
| Continuous Shooting Speed |
Approx. 5 fps (at a shutter speed of 1/(TBA) sec. or faster in all recording modes) |
| Max. Burst During Continuous Shooting |
JPEG: approx. 45 frames
RAW: approx. 15 frames
RAW+JPEG: approx. (TBA) frames (Large/Fine) |
| Monitor Type |
TFT color, liquid-crystal monitor |
| Screen Monitor size |
3.0 in. |
| Pixels |
Approx. 230,000 pixels |
| Coverage |
Approx. 100% |
| Brightness Control |
7 levels provided |
| Image Display Format |
Single image, 4-image index, 9-image index, Jump, AF point, Magnified zoom (approx. 1.5x to 10x), Brightness or RGB Histogram, Auto rotate, Rotate
Live View Function: view image before shooting on LCD monitor; live histogram and live simulation of exposure level possible with C.Fn IV-16-1 |
| Highlight Alert |
In the single image display and (INFO) display, over-exposed highlight areas will blink |
| Protection |
Single image, all images in a folder, or all images in the memory card can be protected or cancel the image protection |
| Erase Modes |
Single image, all images in a folder, all images in the memory card or check-marked images can be erased or unprotected. |
| Direct Printing from the Camera |
Possible with compatible PictBridge-enabled printers |
| Compatible Printers |
CP and SELPHY Compact Photo Printers, PIXMA Photo Printers and PictBridge compatible printers (via USB Interface Cable IFC-200U, included with camera kit) |
| Settings |
Print quantity, style (image, paper size, paper type, printing effects, layout), trimming, tilt correction |
| Dust Delete Feature |
Via built-in microphone at rear of camera body; activated by pressing recording button on camera. Sound file attached to image file on memory card |
| Picture Style |
WAV |
| Recording Time |
Max. 30 sec. per recording |
| Menu Categories |
Shooting
Playback
Setup
Custom function/My Menu |
| LCD Monitor Language |
18 (English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Simplified/Traditional Chinese, Korean, Japanese) |
| Battery |
One dedicated lithium-ion battery pack LP-E4 AC power can be supplied via the AC Adapter Kit ACK-E4 (included) |
| Number of Shots |
At 73°F/23°C: Approx. (TBA)
At 32°F/0°C: Approx. (TBA)
The above figures apply when a fully-charged Battery Pack LP-E4 is used |
| Battery Check |
Automatic, displayed in six levels. Precise readout of percentage remaining, shots taken since last charge, calibration recommended, and approx. remaining battery life are displayed with Battery Info menu setting. |
| Power Saving |
Provided. Power turns off after 1, 2, 4, 8, 15, 30 min. |
| Back-up Battery |
One CR2025 lithium battery |
| Operating Temperature Range |
32-113°F/0-45°C |
| Operating Humidity Range |
85% or less |
| Dimensions |
6.1 x 6.3 x 3.1 in./156 x 159.6 x 79.9mm (W x H x D) |
| Weight |
42.5 oz./1,205g |
| Warranty |
Canon 1 year limited warranty |
