Outstanding Image Quality: 10.1 Megapixel CMOS sensor with DIGIC III Image Processor. |
|
Auto Lighting Optimizer: The EOS Rebel XS's Auto Lighting Optimizer is yet another image-quality tool that comes to the rescue in tricky lighting conditions. It can actually lighten dark areas of a scene while ensuring that bright areas maintain tonal detail |
|
Picture Style Settings: With the EOS Rebel XS's Picture Style technology, photographers can change the look of their digital photographs. Color, saturation, sharpness and contrast settings create noticeable variation in the saved image |
|
High-speed, wide-area 7-point AF with center cross-type sensors:It features a high-speed, wide area 7-point AF system. It can focus using One-Shot AF mode, AI Focus AF, AI Servo AF and Manual. The center, cross-type focus point operates flawlessly in lower-light and lower-contrast settings |
|
Excellent performance with 3.0 fps continuous shooting and burst rate up to 514 Large JPEGs (until memory card is full): With instant startup times, speedy autofocus and minimal shutter lag, the EOS Rebel XS is one of the fastest cameras available today |
|
Large 2.5-inch LCD monitor with Live View Function: The EOS Rebel XS has a bright 2.5-inch TFT LCD monitor with 230,000 pixels and a viewing angle of 170°. It's perfect for Live View composition or viewing camera settings like AF, ISO, Metering, AF Point selection and flash options |
|
Live View Function:Live View Function enables you to view your subjects directly on the 2.5-inch LCD monitor. It's easy to magnify any part of the scene 5x or 10x for precise manual focus. And now, there are two ways to use Autofocus along with Live View Function in the EOS Rebel XS |
|
EOS Integrated Cleaning System: Photographers who must change lenses in dusty environments will find the advanced Canon EOS Integrated Cleaning System a tremendous time saver. Dust that settles on the sensor surface is removed using ultrasonic vibration |
|
Self Cleaning Sensor Unit: A key element of minimizing dust is preventing it from clinging to the front surface of the imaging sensor. To combat against this, the EOS Rebel XS features a Canon-designed Self Cleaning Sensor Unit |
|
Dust Delete Data Detection: Dust that may still remain on the front of the sensor can also be erased with software included in Digital Photo Professional (DPP) Version 3.3 or later software. A simple test shot of a plain, white object can be taken, using a menu setting |
|
Canon's lightest and most compact EOS Digital SLR to date: Measuring 4.96" x 3.8" x 2.4" and weighing in at under 16 oz., the EOS Rebel XS is indeed the smallest digital Rebel ever produced |
|
Compatible with compact SD and SDHC memory cards: Compact, inexpensive and available in increasingly large capacities, SD and SDHC memory cards are a perfect complement to the EOS Rebel XS's compact and lightweight body design |
|
EF & EF-S Lenses: The EOS Rebel XS is compatible with all Canon lenses in the EF and EF-S lineup, ranging from ultra-wide angle to super telephoto lenses |
|
Flash Photography: The EOS Rebel XS features the acclaimed E-TTL II flash metering system. With any of the flashes in the EX Speedlite line, E-TTL II provides reliable flash output whether shooting fill-in flash pictures in sunlight, or using flash in total darkness |
| Type | Digital, single-lens reflex, AF/AE camera with built-in flash |
| Recording Media | SD memory card, SDHC memory card |
| Image Sensor Size | 22.2mm x 14.8mm |
| Compatible Lenses | Canon EF lenses (including EF-S lenses)
35mm-equivalent focal length is approx. 1.6x the lens focal length) |
| Lens Mount | Canon EF mount |
| Image Sensor Type | High-sensitivity, high-resolution, large single-plate CMOS sensor |
| Pixels | Effective pixels: Approx. 10.10 megapixels |
| Total Pixels | Approx. 10.50 megapixels |
| Aspect Ratio | 3:2 (Horizontal: Vertical) |
| Color Filter System | RGB primary color filters |
| Low-pass Filter | Located in front of the image sensor, non-removable |
| Dust Deletion feature | (1) Automatic sensor cleaning
(2) Manual cleaning of sensor
(3) Dust Delete Data appended to the captured image |
| Recording Format | Design rule for Camera File System 2.0 |
| Image Type | JPEG, RAW (12-bit Canon original)
RAW+JPEG |
| File Size | (1) Large/Fine : Approx. 3.8MB (3888 x 2592 pixels)
(2) Large/Normal : Approx. 2.0MB (3888 x 2592 pixels)
(3) Medium/Fine : Approx. 2.3MB (2816 x 1880 pixels)
(4) Medium/Normal: Approx. 1.2MB (2816 x 1880 pixels)
(5) Small/Fine : Approx. 1.3MB (1936 x 1288 pixels)
(6) Small/Normal : Approx. 0.7MB (1936 x 1288 pixels)
(7) RAW : Approx. 9.8MB (3888 x 2592 pixels)
Exact file sizes depend on the subject, ISO speed, Picture Style, etc. |
| File Numbering | Consecutive numbering, auto reset, manual reset |
| RAW + JPEG Simultaneous Recording | Provided |
| Color Space | sRGB, Adobe RGB |
| Picture Style | Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Def. 1-3 |
| Auto White Balance | Auto, Daylight, Shade, Cloudy, Tungsten, White Fluorescent Light, Flash, Custom |
| Color Temperature Compensation | White balance correction: ±9 stops in full-stop increments
White balance bracketing: ±3 stops in full-stop increments
Blue/amber direction or magenta/green direction possible |
| Viewfinder Type | Eye-level pentamirror |
| Coverage | Vertical/Horizontal approx. 95% |
| Magnification | Approx. 0.81x (-1m with 50mm lens at infinity) |
| Eyepoint | Approx. 21mm (from eyepiece lens center) |
| Built-in Dioptric Adjustment | -3.0 to ±1.0m (dpt) |
| Focusing Screen | Fixed, Precision Matte |
| Mirror | Quick-return half mirror (transmission: reflection ratio of 40:60, no mirror cut-off with EF600mm f/4L IS USM or shorter lenses) |
| Viewfinder Information | AF information (AF points, focus confirmation light), exposure information (shutter speed, aperture, AE lock, exposure level, ISO speed, exposure warning), flash information (flash ready, high-speed sync, FE lock, flash exposure compensation), monochrome shooting, white balance correction, maximum burst, SD memory card information |
| Depth-of-Field Preview | Enabled with depth-of-field preview button |
| Autofocus Type | TTL secondary image-registration, phase detection |
| AF Points | 7 AF points |
| Metering Range | EV 0.5-18 (at 73°F/23°C, ISO 100) |
| Focusing Modes | One-Shot AF, AI Servo AF, AI Focus AF, Manual focusing (MF) |
| AF Point Selection | Automatic selection, manual selection |
| Selected AF Point Display | Superimposed in viewfinder and indicated on LCD monitor |
| AF-assist Beam | Small series of flashes fired by built-in flash
Effective range: Approx. 4.0m/13.1 ft. at center, approx. 3.5m/11.5 ft. at periphery |
| Metering Modes | 35-zone TTL full-aperture metering
Evaluative metering (linkable to any AF point)
Partial metering (approx. 10% of viewfinder at center)
Center-weighted average metering |
| Metering Range | EV 1-20 (at 73°F/23°C with EF50mm f/1.4 USM lens, ISO 100) |
| Exposure Control | Program AE (Full Auto, Portrait, Landscape, Close-up, Sports, Night Portrait, Flash Off, Program), shutter-priority AE, aperture-priority AE, depth-of-field AE, manual exposure, E-TTL II autoflash |
| ISO Speed (Recommended Exposure Index) | Basic Zone modes: ISO 100-800 set automatically
Creative Zone modes: ISO 100-1600 (in 1-stop increments), Auto |
| Exposure Compensation | Manual: ±3 stops in 1/3- or 1/2-stop increments (can be combined with AEB)
AEB: ±3 stops in 1/3- or 1/2-stop increments |
| AE Lock | Automatic: When focus achieved with evaluative metering and One-Shot AF
Use-set: By AE lock button |
| Shutter Type | Electronically-controlled, focal-plane shutter |
| Shutter Speeds | 1/4000 sec. to 30 sec., bulb, X-sync at 1/200 sec. (Total shutter speed range. Available range varies by shooting mode.) |
| Shutter Release | Soft-touch electromagnetic release |
| Self-timer | 10-sec. or 2-sec. delay or 10-sec. delay plus continuous shooting |
| Remote Control | Remote Switch RS-60E3 |
| Built-in Flash Type | Retractable, auto pop-up flash |
| Flash Metering | E-TTL II autoflash |
| Guide Number | 13/43 (ISO 100, in meters/feet) |
| Recycling Time | Approx. 3 sec. |
| Flash-ready Indicator | Flash-ready icon lights in viewfinder |
| Flash Coverage | 17mm lens angle of view |
| FE Lock | Provided |
| Flash Exposure Compensation | Up to ±2 stops in 1/3- or 1/2-stop increments |
| Zooming to Match Focal Length | Provided, with Speedlites |
| Compatible Flash | EX-series Speedlites |
| Flash Metering | E-TTL II autoflash |
| Flash Exposure Compensation | ±2 stops in 1/3- or 1/2-stop increments |
| FE Lock | Provided |
| External Flash Settings | Built-in flash and Speedlite 430EX II/ 580EX II can be set on camera's menu |
| Continuous Shooting Speed | Max. approx. 3.0 shots/sec. (single shots possible) |
| Maximum Burst | JPEG (Large/Fine): Approx. 514 (until memory card becomes full); RAW: Approx. 5; RAW+JPEG (Large/Fine): Approx. 4
Based on Canon's testing standards with a 2GB SD memory card, ISO 100 and Standard Picture Style
Varies depending on the subject, card write speed, SD memory card brand, image-recording quality, file size, etc. |
| Shooting Modes | (1) Live View shooting
(2) Remote Live View shooting (with a personal computer installed with EOS Utility) |
| Focusing | Manual focus
Autofocus (Quick mode, Live mode) |
| Metering Modes | Evaluative metering with the image sensor |
| Metering Range | EV 0-20 (at 73°F/23°C with EF 50mm f/1.4 USM lens, ISO 100) |
| Grid Display | Provided |
| Exposure Simulation | Simulated exposure displayed in real-time |
| LCD Monitor Type | TFT color, liquid-crystal monitor |
| Monitor Size | 2.5 in. |
| Dots | Approx. 230,000 |
| Coverage | Approx. 100% (viewing angle: approx. 170°) |
| Brightness Adjustment | 7 levels provided |
| Interface Languages | 20 |
| Display Format | Single image, Single image + Image-recording quality, shooting information, histogram, 4- or 9-image index, magnified view (approx. 1.5x-10x, enable in 15 steps), rotated image, image jump (by 1/10/100 images or shooting date) |
| Highlight Warning | Provided (Overexposed highlights blink) |
| Image Protection and Erase Protect | Single images can be erase-protected or not |
| Erase | Single image, check-marked images, or all images in the card can be erased (except protected images) at one time |
| Compatible Printers | PictBridge-compatible printers |
| Printable Images | JPEG image compliant to Design rule for Camera File System (DPOF printing possible) |
| Easy Print feature | Provided |
| Compatible Images | JPEG and RAW images
Only JPEG images can be transferred as wallpaper on the personal computer screen |
| Custom Functions | Total 12 |
| My Menu Registration | Provided |
| USB Terminal | For personal computer communication and direct printing (USB 2.0 Hi-Speed) |
| Video Out Terminal | NTSC/PAL selectable |
| Battery | One Battery Pack LP-E5
AC power can be supplied via optional AC Adapter Kit ACK-E5 (with optional Battery Grip BG-E5, AA-size batteries can be used) |
| Battery Check | Auto |
| Power Saving | Provided. Power turns off after 30 sec., 1, 2, 4, 8 or 15 min. |
| Date/Time Battery | Built-in secondary battery |
| Start-up Time | Approx. 0.1 sec. (Based on CIPA testing standards) |
| Working Temperature Range | 32-104°F/0-40°C |
| Working Humidity Range | 85% or less |
| Dimensions (WxHxD) | Approx. 4.96 x 3.8 x 2.4 in./126.1 x 97.5 x 61.9mm |
| Weight | Approx. 15.9 oz./ 450g (body only) |
| Warranty | Canon 1 year limited warranty |
| | |
