| Sensor |
1/2.3-inch CMOS |
| Total Pixels |
Approx. 16.8 Megapixels |
| Effective Pixels |
Approx. 16.1 Megapixels |
| Focal Length |
4.3 (W) to 21.5mm (T) (35mm film equivalent: 24 to 120mm) |
| Digital Zoom |
Approx. 4x |
| Focusing Range |
Normal: 2.0 in. (5cm) to infinity (W), 3.0 ft. (90cm) to infinity (T)
Auto: 1.2 in. (3cm) to infinity (W), 3.0 ft. (90cm) to infinity (T)
Macro: 1.2 in. to 1.6 ft. (3-50cm) (W) |
| Autofocus System |
TTL Autofocus |
| LCD Monitor |
3.2-inch TFT Touch Panel Color LCD with wide viewing angle |
| LCD Pixels |
Approx. 461,000 dots |
| LCD Coverage |
Approx. 100% |
| Maximum Aperture |
f/2.7 (W) to f/5.9 (T) |
| Shutter Speed |
1-1/2000 sec.
15-1/2000 sec. (Total shutter speed range) |
| Sensitivity |
Auto, ISO 100/200/400/800/1600/3200 (in P mode) |
| Light Metering Method |
Evaluative, Center weighted average, Spot |
| Exposure Control Method |
AE Lock |
| Exposure Compensation |
+/-2 stops in 1/3-stop increments (not available when shooting movies) |
| White Balance Control |
Auto, Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Custom |
| Built-in Flash |
Auto, Flash On, Slow Synchro, Flash Off |
| Flash Range |
1.6 to 11 ft. (W), 3.0 to 6.6 ft. (T) (50cm to 3.5m (W), 90cm to 2.5m (T)) |
| Recycling Time |
10 seconds or less (battery voltage: 3.7 V) |
| Shooting Modes |
Auto, P, Movie Digest, Portrait, Smooth Skin, Smart Shutter, High-speed Burst, Handheld Night Scene, Low Light, Fish-eye Effect, Miniature Effect, Toy Camera Effect, Soft Focus, Monochrome, Super Vivid, Poster Effect, Color Accent, Color Swap, Snow, Long Shutter, iFrame Movie, Super Slow Motion Movie |
| Photo Effects |
My Colors Off, Vivid, Neutral, Sepia, Black & White, Positive Film, Lighter Skin, Darker Skin, Vivid Blue, Vivid Green, Vivid Red, Custom Color |
| Self Timer |
Approx. 10-sec. delay/approx. 2-sec. delay/custom |
| Continuous Shooting |
Approx. 1.9 shots/sec. (In P mode)
Approx. 5.2 shots/sec. (In High-speed Burst mode) |
| Storage Media |
SD memory card, SDHC memory card, SDXC memory card |
| File Format |
Design rule for Camera File system, DPOF (Version 1.1) compliant |
| Image Recording Format |
Superfine, Fine |
| JPEG Compression Mode |
Still Image: Exif 2.3 (JPEG)
Video: MOV (Image: H.264; Audio: Linear PCM (2-channel Stereo)) |
| Number of Recording Pixels: Still Images |
[16:9]
Large: 4608 x 2592, Medium 1: 3264 x 1832
Medium 2: 1920 x 1080, Small: 640 x 360 [3:2]
Large: 4608 x 3072, Medium 1: 3264 x 2176
Medium 2: 1600 x 1064, Small: 640 x 424
[4:3]
Large: 4608 x 3456, Medium 1: 3264 x 2448
Medium 2: 1600 x 1200, Small: 640 x 480
[1:1]
Large: 3456 x 3456, Medium 1: 2448 x 2448
Medium 2: 1200 x 1200, Small: 480 x 480 |
| Number of Recording Pixels Videos |
[iFrame Movie]
1280 x 720 (30 fps)
[Super Slow Motion Movie] 640 x 480, 320 x 240
[Miniature Effect] 1280 x 720, 640 x 480
[Other than the above] 1920 x 1080 (24 fps), 1280 x 720 (30 fps), 640 x 480 (30 fps) |
| Playback Modes File Stills & Videos |
Auto Rotate (Automatic vertical/horizontal detection), Image Advance (Operation Tools, Transition Effects, Scroll Display, Active Display), Rotate, Favorites, My Category, Smart Shuffle, Group Playback, Image Search, Movie Digest, Slideshow (Playback Interval, Repeat, Effect, Playlist) |
| Playback Modes File Still Images |
Single, Index (6-130 thumbnails), Magnification (2-10x), Information Display, Red-eye Correction, i-Contrast, Trimming, Resize, My Colors, Focus Check, Histogram, Overexposure Warning |
| Playback Modes File Videos |
Normal Playback, Skip Backward, Previous Frame, Next Frame, Skip Forward |
| Erase Modes |
Select, Select Range, Select All Images |
| Computer Interface |
Hi-Speed USB (Dedicated connector (female) with unified type of digital, audio and video |
| Video Out |
NTSC/PAL (dedicated connector (female) with unified type of digital, audio and video) |
| Audio Out |
2-channel Stereo (dedicated connector (female) with unified type of digital, audio and video) |
| Other Interfaces |
Mini-HDMI cable: connection to high definition monitor; SD memory card slot; direct connection to Canon SELPHY Compact Photo Printers, PIXMA Inkjet Photo Printers and PictBridge-compatible printers via camera's USB 2.0 Hi-speed cable |
| Power Source |
Battery Pack NB-11L, Compact Power Adapter CA-DC10 (included with AC Adapter Kit ACK-DC90) |
| Shooting Capacity |
Approx. 170 shots |
| Playback Time |
Approx. 3 hours |
| Operating Temperature |
32 to 104Deg.F/0 to 40Deg.C |
| Operating Humidity |
10 to 90% |
| Dimensions (W x H x D) |
3.68 x 2.24 x 0.82 in. / 93.5 x 56.8 x 20.8mm |
| Weight |
5.11 oz. / 145g (including the batteries and memory card)
4.95 oz. / 130g (camera only) |
