| Type |
8.0 Megapixel, 1/1.8 inch charge coupled device (CCD) |
| Total Pixels |
Approx. 8.3 Megapixels |
| Effective Pixels |
Approx. 8.0 Megapixels |
| Lens Type |
UA Lens Technology |
| Optical Zoom |
3.6x |
| Focal Length |
5.8-20.7mm f/2.8-5.3 zoom lens (equivalent to 28-100mm in 35mm format) |
| Digital Zoom |
4x |
| Focusing Range |
Normal AF: 1.4 ft./44cm-infinity;
Macro AF: 1.6 in.-1.4 ft./4-44cm (WIDE),
11.8 in. - 1.4 ft./30-44cm (TELE);
Digital Macro: 1.6 in. - 1.4 ft./4-44cm (WIDE) |
| Aperture Range |
maximum Aperture; f/2.8 (W) - f/5.3 (T) |
| Type |
8.0 Megapixel, 1/1.8 inch charge coupled device (CCD) |
| Sensitivity |
AUTO, ISO 50/100/200/400 equivalent |
| Shutter Speed |
15-1/2000 sec.; Slow shutter speed operates with noise reduction when manually set at 1.3-15 sec. |
| Light Metering Method |
Evaluative, Center-weighted average, Spot*
* Metering frame with Spot Mode is fixed to center or linked to AF frame. |
| Exposure Control Modes |
Program AE, Shutter-priority AE, Aperture-priority AE, Manual, Custom AE Lock is available
Auto; Creative Zone: P, Av, Tv, M, C; Image Zone: Special Scene (Portrait, Landscape, Night Scene, Foliage, Snow, Beach, Fireworks, Underwater, Indoor, Kids & Pets, Night Snapshot, Digital Macro), My Colors, Stitch Assist, Movie |
| Photo Effects (Color Modes) |
Vivid, Neutral, Low Sharpening, Sepia, Black & White, Custom |
| Exposure Compensation |
+/- 2 stops in 1/3-stop increments |
| White Balance System |
Auto, Preset (Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Flash, Underwater), Custom |
| Flash Modes |
Operation Modes: Auto, On/Off, Red-Eye Reduction On/Off, Slow Synchro |
| Flash Range |
Normal: 1.8-13.8 ft./55cm-4.2m (W), 1.8-6.6 ft./55cm-2.0m (T) (When ISO is set to Auto) |
| Total Pixels |
Approx. 8.3 Megapixels |
| Flash Exposure Compensation |
+/- 2 stops in 1/3-stop increments |
| Continuous Shooting |
Approx. 1.8 fps |
| Self-Timer |
Activates shutter after an approx. 2 sec./10 sec. delay, Custom |
| Storage Media |
SD Memory Card, MultiMediaCard |
| File Format |
Design rule for camera file system, DPOF Version 1.1 (Digital Print Order Format) |
| Image Compression |
Still Image: Exif 2.2 (JPEG)
Movie: AVI (Image: Motion JPEG; Audio: WAVE (Monaural)) |
| JPEG Compression Modes |
Normal, Fine, SuperFine |
| Adjustable Resolutions |
Still Image: 3,264 x 2,448 (Large), 2,592 x 1,944 (Medium 1), 2,048 x 1,536 (Medium 2), 1,600 x 1,200 (Medium 3), 640 x 480 (Small)
Movie: 1,024 x 768 (15 fps), 640 x 480/320 x 240 (30 fps/15 fps), 160 x 120 (3 min. at 15 fps) |
| Computer Interface |
USB 2.0 Hi-Speed |
| Effective Pixels |
Approx. 8.0 Megapixels |
| Audio Out |
Monaural |
| Other |
Memory card slot. Direct connection to Canon CP, SELPHY, PIXMA Photo Printers and PictBridge compatible printer via camera's USB cable. |
| Viewfinder |
Real-image optical zoom viewfinder |
| LCD Display |
2.5 inch low-temperature polycrystalline silicon TFT color LCD with wide viewingangle, 100% Coverage |
| Playback Options |
Still Image: Magnification (approx. 2x-10x), Jump, Auto Rotate, Rotation, Histogram, Single, Index (9 thumbnails), Sound Memos, Slide Show
Movie: Normal Playback, Special Playback, Slow motion, Editing |
| Power Source |
1. Rechargeable Lithium Battery NB-2LH
2. AC Adapter Kit ACK-DC20 |
| Shooting Capacity |
Still Image: approx. 200 shots (NB-2LH/LCD On), approx. 700 shots (NB-2LH/LCD Off) |
| Dimensions |
4.09 (W) x 2.24 (H) x 1.53 (D) in./104.0 (W) x 57.0 (H) x 38.8 (D) mm |
| Weight |
Approx. 7.94 oz./225g (camera body only) |
| Lens Type |
UA Lens Technology |
| Optical Zoom |
3.6x |
| Focal Length |
5.8-20.7mm f/2.8-5.3 zoom lens (equivalent to 28-100mm in 35mm format) |
| Digital Zoom |
4x |
| Focusing Range |
Normal AF: 1.4 ft./44cm-infinity;
Macro AF: 1.6 in.-1.4 ft./4-44cm (WIDE),
11.8 in. - 1.4 ft./30-44cm (TELE);
Digital Macro: 1.6 in. - 1.4 ft./4-44cm (WIDE) |
| Aperture Range |
maximum Aperture; f/2.8 (W) - f/5.3 (T) |
| Focusing Type |
TTL Autofocus (continuous/single) |
| Sensitivity |
AUTO, ISO 50/100/200/400 equivalent |
| Shutter Speed |
15-1/2000 sec.; Slow shutter speed operates with noise reduction when manually set at 1.3-15 sec. |
| Light Metering Method |
Evaluative, Center-weighted average, Spot*
* Metering frame with Spot Mode is fixed to center or linked to AF frame. |
| Exposure Control Modes |
Program AE, Shutter-priority AE, Aperture-priority AE, Manual, Custom AE Lock is available
Auto; Creative Zone: P, Av, Tv, M, C; Image Zone: Special Scene (Portrait, Landscape, Night Scene, Foliage, Snow, Beach, Fireworks, Underwater, Indoor, Kids & Pets, Night Snapshot, Digital Macro), My Colors, Stitch Assist, Movie |
| Photo Effects (Color Modes) |
Vivid, Neutral, Low Sharpening, Sepia, Black & White, Custom |
| Exposure Compensation |
+/- 2 stops in 1/3-stop increments |
| White Balance System |
Auto, Preset (Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Flash, Underwater), Custom |
| Flash Modes |
Operation Modes: Auto, On/Off, Red-Eye Reduction On/Off, Slow Synchro |
| Flash Range |
Normal: 1.8-13.8 ft./55cm-4.2m (W), 1.8-6.6 ft./55cm-2.0m (T) (When ISO is set to Auto) |
| Recycling Time |
Approx. 10 sec. or less (battery voltage=7.4V) |
| Flash Exposure Compensation |
+/- 2 stops in 1/3-stop increments |
| Continuous Shooting |
Approx. 1.8 fps |
| Self-Timer |
Activates shutter after an approx. 2 sec./10 sec. delay, Custom |
| Storage Media |
SD Memory Card, MultiMediaCard |
| File Format |
Design rule for camera file system, DPOF Version 1.1 (Digital Print Order Format) |
| Image Compression |
Still Image: Exif 2.2 (JPEG)
Movie: AVI (Image: Motion JPEG; Audio: WAVE (Monaural)) |
| JPEG Compression Modes |
Normal, Fine, SuperFine |
| Adjustable Resolutions |
Still Image: 3,264 x 2,448 (Large), 2,592 x 1,944 (Medium 1), 2,048 x 1,536 (Medium 2), 1,600 x 1,200 (Medium 3), 640 x 480 (Small)
Movie: 1,024 x 768 (15 fps), 640 x 480/320 x 240 (30 fps/15 fps), 160 x 120 (3 min. at 15 fps) |
| Computer Interface |
USB 2.0 Hi-Speed |
| Video Output |
NTSC/PAL |
| Audio Out |
Monaural |
| Other |
Memory card slot. Direct connection to Canon CP, SELPHY, PIXMA Photo Printers and PictBridge compatible printer via camera's USB cable. |
| Viewfinder |
Real-image optical zoom viewfinder |
| LCD Display |
2.5 inch low-temperature polycrystalline silicon TFT color LCD with wide viewingangle, 100% Coverage |
| Playback Options |
Still Image: Magnification (approx. 2x-10x), Jump, Auto Rotate, Rotation, Histogram, Single, Index (9 thumbnails), Sound Memos, Slide Show
Movie: Normal Playback, Special Playback, Slow motion, Editing |
| Power Source |
1. Rechargeable Lithium Battery NB-2LH
2. AC Adapter Kit ACK-DC20 |
| Shooting Capacity |
Still Image: approx. 200 shots (NB-2LH/LCD On), approx. 700 shots (NB-2LH/LCD Off) |
| Dimensions |
4.09 (W) x 2.24 (H) x 1.53 (D) in./104.0 (W) x 57.0 (H) x 38.8 (D) mm |
| Weight |
Approx. 7.94 oz./225g (camera body only) |
| Operating Temperature |
32-104° F/0-40° C |
