| Print method |
9 pin, serial impact dot matrix |
| Print font |
7 x 9/9 x 9 |
| Column capacity |
40 or 42 columns/33 or 35 columns |
| Character size |
1.24 x 3.1mm (W x H)/1.56 x 3.1mm (W x H); {0.049 x 0.122"/0.061 x 0.122"} |
| Character set |
95 Alphanumeric, 32 International, 128 x 8 Graphic |
| Characters per inch |
16 or 17.8 cpi/13.3 or 14.5 cpi |
| Interface |
RS-232C, Bi-directional parallel, Connect-It |
| Data buffer |
4KB/45 bytes |
| Print speed |
Approx. 3.5 lps (at 40-column printing)/approx. 6.4 lps (at 16-column printing) |
| Paper dimensions |
Maximum print lines: 9 lines
Receipt: 76 ± 0.5 x diameter 83mm (2.99 ± 0.02 x diameter 3.27")
Validation: 135 to 182 x 70 to 182mm (W x L) {5.31 to 7.17 x 2.76 to 7.17"} |
| Paper thickness |
Receipt: 0.06 to 0.085mm [0.0024 to 0.0033"]/sheet (total thickness: 0.2mm [0.079"] or less)
Validation: 0.09 to 0.12mm [0.0035 to 0.0047"]/sheet (total thickness: 0.09 to 0.31mm) [0.0035 to 0.012"], (including the thickness of roll paper) |
| Copy capability |
One original and two copies |
| Inked ribbon |
ERC-38 (purple, black) |
| Ribbon life |
4,000,000 characters (purple), 3,000,000 characters (black) |
| Power supply |
AC adapter (included), PS-180 (option) |
| Power consumption |
Approx. 43W |
| D.K.D. function |
2 drivers |
| Reliability |
MTBF: 180,000 hours
MCBF: 49,000,000 lines |
| Dimensions (W x D x H) |
164 x 240 x 136mm {6.46" x 9.45" x 5.35"} |
| Weight |
Approx. 2.3 kg (5.07 lbs) |
