| Input Signal |
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/PAL60/SECAM |
| Display Performance NTSC |
480 lines |
| Display Performance PAL |
560 lines(depends on observation of the multi-burst pattern) |
| Computer/component video |
D-sub 15 pin x 2 |
| S-video |
Mini DIN x 1 |
| Composite video |
RCA x 1 |
| Audio |
Audio in x 3 (RCA (L&R) x 1, mini stereo x 2) |
| Variable audio out |
mini stereo x 1 |
| USB connector |
Type B x 1 (USB display and mouse/keyboard control), Type A x 2 (for USB memory device/Epson doc camera) |
| Serial |
RS-232c x 1 |
| LAN networking |
RJ-45 x 1 |
| Monitor out |
Mini D-sub 15 pin x1 |
| Wireless LAN port |
802.11 a/b/g |
| Projection System |
Epson 3LCD, 3-chip optical engine |
| Projection Method |
Front/rear/ceiling mode |
| Driving Method |
Epson Poly-silicon TFT Active Matrix |
| Pixel Number |
1,024,000 dots (1280 x 800) x 3 |
| White Light Output |
4000 lumens (ISO 21118 standard) |
| Color Light Output |
4000 lumens |
| Aspect Ratio |
16:10 |
| Native Resolution |
1280 x 800 (WXGA) |
| Resize |
640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (SXGA), 1440 x 900 (WSXGA), 1680 x 1050 (WSXGA+), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA) |
| Throw Ratio Range |
1.62 - 2.61 |
| Plug 'n Play |
Mac compatible via DVI to VGA adapter (not included) USB Plug 'n Play for Windows 2000 or later |
| Projection Lens Type |
Powered focus Manual (optical) zoom |
| Projection Lens F-number |
1.75 - 2.42 |
| Projection Lens focal length |
24 mm - 38.2 mm |
| Projection Lens Zoom Ratio |
Optical zoom 1.0 - 1.6 |
| Lamp type |
E-TORL 230 W UHE |
| Lamp life |
Up to 3500 hours (ECO Mode) Up to 2500 hours (Normal Mode) |
| Screen Size: (Projected Distance) |
30" - 300" 16:10 aspect (3' - 50.6') |
| Keystone Correction |
Automatic Vertical: ± 30 degrees (± 45 degrees) Horizontal: ± 20 degrees (± 30 degrees) |
| Contrast Ratio |
Up to 2000:1 |
| Color Reproduction |
16.77 million colors |
| Sound Output |
10 W (mono) |
| Operating Temperature |
41 ° to 95 °F (5 ° to 35 °C) |
| Power Supply Voltage |
100 - 240 V ±10%, 50/60 Hz |
| Power Consumption |
341 W Communication on: 5.5 W standby Communication off: 0.2 W standby |
| Remote Control features |
Search, comp, video, USB, LAN, power, aspect, color mode, volume, e-zoom, A/V mute, freeze, menu, page up and down, help, auto, mouse functions, user, ID num, pointer, esc, enter |
| Operating Angle |
Right/left: ±30 degrees Upper/lower: ± 30 degrees |
| Operating Distance |
26' (8 m) |
| Security |
Kensington-style lock provision, security anchor bar |
| Fan Noise |
29 dB (ECO Mode) 37 dB (Normal Mode) |
| Dimension(W x D x H) |
Including feet: 14.1" x 10.12 x 3.4" Excluding feet: 14.1" x 10.12" x 3.74" |
| Weight |
7.82 lb |
| Warranty |
Epson 2 years projector & 90 days lamp limited warranty |
