| Projection System |
RGB liquid crystal shutter |
| Projection Method |
Front / rear / ceiling mount |
| Driving Method |
Poly-silicon TFT Active Matrix |
| Pixel Number |
786,432 dots (1024 x 768) x 3 |
| White Light Output |
3000 lumens (ISO 21118 Standard) |
| Color Light Output |
3000 lumens |
| Aspect Ratio |
4:3 |
| Native Resolution |
1024 x 768 (XGA) |
| Resize |
640 x 480 (VGA), 800 x 600 (SVGA), 1152 x 864 (SXGA), 1280 x 800 (WXGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1280 x 768 (WXGA 60-1), 1360 x 768 (WXGA 60-2), 1440 x 900 (WXGA+), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA) |
| Lamp Type |
E-TORL 230 W UHE |
| Lamp Life |
ECO mode: Up to 6000 hours
Normal mode: Up to 4000 hours |
| Throw Ratio Range |
0.54 - 0.74 |
| Size (projected distance) |
50" - 108" (0.54 - 1.22 m) |
| Keystone Correction |
Manual:
Vertical: ±15 degrees
Horizontal: ±15 degrees |
| Contrast Ratio |
Up to 3000:1 |
| Color Reproduction |
16.77 million colors |
| Projection Lens type |
No optical zoom / Manual focus |
| F-number |
1.8 |
| Focal Length |
6.48 mm |
| Zoom Ratio |
Digital 1.0 - 1.35 |
| Display Performance |
NTSC: 480 lines
PAL: 576 lines |
| Input Signal |
NTSC / NTSC4.43 / PAL / M-PAL /N-PAL / PAL60 / SECAM |
| Interfaces |
Computer / Component video: D-sub 15 pin x 2
S-video: Mini DIN x 1
Composite video: RCA (Yellow) x 1
Audio in: RCA x 1 (L and R), mini stereo x 2
USB connector: Type B x 1 (USB display, audio and mouse control)
USB connector: Type A x 1 (USB memory / document camera)
HDMI x 1
RJ-45 x 1
Serial: RS-232c x 1
Monitor out: D-sub 15 pin x 1
Audio out: Mini stereo x 1
Microphone: Mini stereo x 1
Wireless LAN port: 802.11 b/g/n (optional - module sold separately) |
| Speaker |
16W monaural |
| Operating Temperature |
41Deg. to 95Deg.F (5Deg. to 35Deg.C) |
| Power Supply Voltage |
100 - 240 V, ±10%, 50/60 Hz AC |
| Power Consumption |
ECO mode: 241 W
Normal mode: 332 W
Communication on: 6.80 W standby
Communication off: 0.28 W standby |
| Fan Noise |
Low Light Output mode: 29 dB
High Light Output mode: 37 dB |
| Security |
Kensington-style lock provision
Padlock and security cable hole
Password protection function |
| Remote Control: Operating Angle |
Upper / Lower: 10 to +70 degrees
Right / Left: ±30 degrees |
| Remote Control: Operating Distance |
19.7 ft (6 m) |
| Dimensions (W x D x H) |
Including feet: 13.6" x 11.7" x 6.2" (34.5 x 29.7 x 15.7 cm)
Excluding feet: 13.6" x 10.9" x 4.1" (34.5 x 27.6 x 10.4 cm) |
| Weight |
8.7 lb (3.9 kg) |
