| Computer/component video |
D-sub 15 pin x 2 |
| S-video |
Mini DIN x 1 |
| Composite video |
RCA x 1 |
| Audio in x 3 |
RCA (L&R) x 1, mini stereo x 2 |
| Variable audio out |
Mini stereo x 1 |
| LAN networking |
RJ-45 x 1 |
| Serial |
RS-232c x 1 |
| Monitor out |
D-sub 15 pin x 1 |
| USB |
USB Type B x 1 (USB display, mouse, keyboard interface) USB Type A x 1 (USB memory device) |
| Wireless port |
802.11 a/b/g |
| Projection System |
Epson 3LCD, 3-chip optical engine |
| Projection Method |
Front/rear/wall/ceiling mount |
| Driving Method |
Epson Poly-silicon TFT Active Matrix |
| Pixel Number |
786, 432 dots (1024 x 768) x 3 |
| White Light Output |
3000 lumens (ISO 21118 Standard) |
| Color Light Output |
3000 lumens |
| Aspect Ratio |
4:3 |
| Native Resolution |
1024 x 768 (XGA) |
| Resize |
640 x 480 (VGA), 800 x 600 (SVGA) 1280 x 800 (WXGA), 1152 x 864 (SXGA1), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3) 1280 x 768 (WXGA60-1), 1360 x 768 (WXGA60-2) 1440 x 900 (WXGA+), 1400 x 1050 (SXGA+) 1600 x 1200 (UXGA) |
| Throw Ratio Range |
(4:3) 0.37:1 -0.50:1 (16:10) 0.37:1 -0.50:1 (16:9) 0.37:1 -0.50:1 |
| Plug 'n Play |
Projector is Mac compatible DVI or HDMI to VGA USB Plug 'n Play for Windows 2000 or later |
| Projection Lens Type |
Manual focus |
| F-number |
1.8 |
| Focal Length |
4.68 mm |
| Zoom Ratio |
Digital 1.0 -1.35x |
| Lamp Type |
E-TORL 230 W UHE |
| Lamp Life |
Up to 3500 hours (ECO Mode) Up to 2500 hours (Normal Mode) |
| Screen Size (Projected Distance) |
4:3 (63" -102") 16:10 (60"-96") 16:9 (60" -93") |
| Keystone Correction |
Vertical: ±5 degrees |
| Contrast Ratio |
Up to 2000:1 |
| Color Reproduction |
16.77 million colors |
| Sound Output |
10W monaural |
| Operating Temperature |
41 ° to 95 °F (5 ° to 35 °C) |
| Power Supply Voltage |
100-240 V±10%, 50/60 Hz AC |
| Power Consumption |
363 W Network on: 10 W standby Network off: 0.3 W standby Direct power on/off Instant off |
| Fan Noise |
35 dB (Normal Mode) 28 dB (ECO Mode) |
| Display Performance |
NTSC: 480 line PAL: 560 line (depends on observation of the multi-burst pattern) |
| Input Signal |
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/PAL60/SECAM |
| Security |
Kensington-style lock provision, security anchor (metal) bar, password protection function |
| Dimension (W x D x H) |
Max: 19.0" x 14.52" x 6.1" Min: 19.0" x 14.52" x 4.5" |
| Weight |
12.9 lb (without slide plate) 14.1 lb (with slide plate) |
